TECHNICAL DATA
Type
Production code
Rated speed
Thread diameter capacity
Die heads
Oil capacity
Frequency band(s) of Bluetooth
Maximum radio-frequency power transmitted in the frequency
band(s)
Bluetooth version
Weight according EPTA-Procedure 01/2014
Recommended ambient operating temperature
Recommended battery types
Recommended charger
Noise Information: Measured values determined according
to EN 62841.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level / Uncertainty K
Sound power level / Uncertainty K
Wear ear protectors.
WARNING!
The vibration and noise emission level given in this information sheet has been measured in accordance with a standardized
test given in EN 62841 and may be used to compare one tool with another. It may be used for a preliminary assessment of
exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for diff erent
applications, with diff erent accessories or poorly maintained, the vibration emission may diff er. This may signifi cantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when
it is running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration and/or noise such as: maintain the tool
and the accessories, keep the hands warm, organization of work patterns.
WARNING
Read all safety warnings, instructions,
illustrations and specifi cations provided with this power
tool. Failure to follow all instructions listed below may result
in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
THREADING MACHINE SAFETY WARNINGS
Keep fl oor dry and free of slippery materials such as oil.
Slippery fl oors invite accidents.
Restrict access or barricade the area from bystanders
when the workpiece extends beyond the machine to
provide a minimum of one metre clearance from the
workpiece. Restricting access or barricading the work area
around the workpiece v/ill reduce the risk of entanglement.
Do not wear gloves. Gloves may be entangled by the
rotating pipe or machine parts leading to personal injury.
Do not use the machine for other purposes such as
drilling holes or turning winches. Other uses or modifying
this machine for other applications may increase the risk of
serious injury.
Secure the machine to a bench or stand. Support long
heavy pipe with pipe supports. This practice will prevent
the machine from tipping.
While operating the machine, stand on the side where the
operator control switch is located. Operating the machine
from this side eliminates need to reach over the machine.
Keep hands away from rotating pipe and fi ttings. Stop
the machine before wiping pipe threads or screwing on
fi ttings. Allow the machine to come to a complete stop
44
MXF PTR2
Threading machine
4000 4972 45 XXXXXX MJJJJ
39 / 59 min
-1
1/8" – 2 "
DN6 – DN50
1/8" – 3/8"
1/2" – 3/4"
DN6 – DN10
DN15 – DN20
DN25 – DN50
3,8 l
1,8 dBm
2.402 – 2.480 GHz
4.0
115 kg
-18...+50 °C
MXF CP203, MXF XC406
MXF C
81,54 dB(A) / 3 dB(A)
92,54 dB(A) / 3 dB(A)
before touching the pipe. This practice will reduce the risk
of entanglement in rotating parts.
Do not use this machine to install or remove fi ttings.
This practice could lead to trapping, entanglement and loss
of control.
Do not operate the machine without all covers properly
installed. Exposing moving parts increases the probability of
entanglement.
Do not use this machine if the foot switch is broken
or missing. The foot switch provides safe control of
the machine, such as emergency shutoff in case of
entanglement.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Use protective equipment. Always wear safety glasses when
working with the machine.
Do not wear gloves while working.
Do not reach into the machine while it is running.
Chips and splinters must not be removed while the machine
is running.
Remove the battery pack before starting any work on the
machine.
Do not dispose of used battery packs in the household refuse
or by burning them. Milwaukee Distributors off er to retrieve
old batteries to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
ENGLISH
Use only System MXF chargers for charging System MXF
battery packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store only
in dry rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme
load or extreme temperatures. In case of contact with battery
acid wash it off immediately with soap and water. In case
1" – 2"
of eye contact rinse thoroughly for at least 10 minutes and
immediately seek medical attention.
Warning! To reduce the risk of fi re, personal injury, and
product damage due to a short circuit, never immerse your
tool, battery pack or charger in fl uid or allow a fl uid to fl ow
inside them. Corrosive or conductive fl uids, such as seawater,
certain industrial chemicals, and bleach or bleach containing
products, etc., can cause a short circuit.
SPECIFIED CONDITIONS OF USE
The thread cutter is suitable for cutting threads on pipes.
Do not use this product in any other way as stated for normal
use.
RESIDUAL RISK
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise in use and the
operator should pay special attention to avoid the following:
• Injury caused by vibration.
Hold the product by designated handles and restrict
working time and exposure.
• Exposure to noise can cause hearing injury.
Wear ear protection and limit exposure.
• Injury due to fl ying debris
Wear eye protection, heavy long trousers and substancial
footwear at all times.
• Inhalation of toxic dusts.
ONE-KEY™
To learn more about the ONE-KEY functionality for this
tool, please reference the Quick Start guide included with
this product or go to www.milwaukeetool.com/one-key. To
download the ONE-KEY app, visit the App Store or Google
Play from your smart device.
Also, when the product experiences ESD, the Bluetooth
communication will be disconnected. It needs to be reset
manually to recover.
ONE-KEY™ Indicator
Wireless mode is active and ready to be
Solid Blue
confi gured via the ONE-KEY™ app.
Tool is actively communicating with the
Blinking Blue
ONE-KEY™ app.
Tool is in security lockout and can be
Blinking Red
unlocked by the owner via the ONE-
KEY™ app.
NOTES FOR LI-ION BATTERIES
Use of Li-Ion batteries
Battery packs which have not been used for some time
should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the
performance of the battery pack. Avoid extended exposure to
heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept
clean.
For an optimum life-time, the battery packs have to be fully
charged, after used.
To obtain the longest possible battery life remove the battery
pack from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C
and away from moisture
Store the battery packs in a 30% - 50% charged condition
Every six months of storage, charge the pack as normal.
Battery protection for Li-Ion batteries
In extremely high torque, binding, stalling and short circuit
situations that cause high current draw, the tool will vibrate for
about 5 seconds, the fuel gauge will fl ash,and then the tool
will turn OFF. To reset, release the trigger.
Under extreme circumstances, the internal temperature of the
battery pack could raise too much. If this happens, the fuel
gauge will fl ash until the battery pack cooled down. After the
lights go off , the work may continue.
Transport of Lithium batteries
Lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements.
Transportation of those batteries has to be done in
accordance with local, national and international provisions
and regulations.
• The user can transport the batteries by road without further
requirements.
• Commercial transport of Lithium-Ion batteries by third par-
ties is subject to Dangerous Goods regulations. Transport
preparation and transport are exclusively to be carried out
by appropriately trained persons and the process has to be
accompanied by corresponding experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and
insulated to prevent short circuit.
• Ensure that battery pack is secured against movement
within packaging.
• Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice
FUNCTIONAL DESCRIPTION
1 Button for activating the machine
2 LED activated machine
3 Speed control
4 Direction control
5 Fuel gauge
6 Overtemperatuture indicator light
7 OnekeyTM indicator
8 Cord holders
9 Battery door
10 Stand latch
11 Wheels
12 Foot switch
13 Hammer chucks
14 Cutting wheel
15 Die head
16 Reamer
17 Carriage handles
18 Debris tray
19 Drain plug
20 Carriage assembly lever
21 Stand handles
ENGLISH
45
