Sungrow AW-AM510-I Kurzanleitung Zur Installation Seite 15

Communication Cable Connection / Anschließen des Kommunikationskabels / Branchement
du câble de communication / Anslutning av kommunikationskablar / Σύνδεση καλωδίου
επικοινωνίας
Option 1: Ethernet cable connection
1
Option 2: SIM card installation
2
LED Indicators / LED-Anzeigen / Voyants DEL / LED-indikatorer / Ενδεικτικές λυχνίες LED
Indicator Indicator Status
Steady green
Top indicators
Breathing blue
Steady blue
Steady red
Blink blue
Energy Star-Ring
Steady blue
Steady red
2
1
Charger Status
Charging connector in
standby state
Charging connector in
use for charging
Fully charged
Fault
Waiting for the user to
swipe a card
Charger works normally
Fault with the charger
3
M2M
25 mm
SIM
15 mm
3
Remark
Normal. Indicators for the left and right connector
are independent of each other.
Normal. Indicators for the left and right connector
are independent of each other.
Normal. Indicators for the left and right connector
are independent of each other.
Normal. Indicators for the left and right connector
are independent of each other.
Normal.
Normal.
Abnormal. In case of a fault with only one of the
charging connectors, the indicator is still steady blue.
