Introduction
Congratulations on the purchase of your
new appliance . You have selected a high-
quality product . The operating instructions
are part of this product . They contain important
information about safety, usage and disposal .
Before using the product, please familiarise your-
self with all operating and safety instructions . Use
the product only as described and for the range
of applications specified . Please also pass these
operating instructions on to any future owner .
Intended use
The cordless hammer drill PABH 20-Li B2
(hereinafter appliance) is suitable for:
▯ Hammer-drilling into brickwork, concrete and
stone
▯ Drilling into stone, wood and metal
▯ Screwing into wood and metal
Any other usage of or modification to the appliance
is deemed to be improper and carries a significant
risk of accidents .
The manufacturer accepts no responsibility for
damage(s) attributable to misuse .
The appliance is not intended for commercial use .
Depicted components
SDS-plus tool holder
Dust protection cap
Locking collar
"Drill/hammer drill" switch
Rotation direction switch
On/Off switch
Battery charge level button
Battery display LED
Battery pack
Release button for the battery pack
LED work light
High-speed charger
Red charge control LED
Green charge control LED
Drill with hexagonal shank
Drill with SDS-plus fitting
■ 2 │ GB │ IE │ NI │ CY
Screwdriver bits
SDS bit adapter
Locking collar
Tool holder
Universal bit holder
Grease
Package contents
1 cordless hammer drill PABH 20-Li B2
1 high-speed charger PLG 20 A1
1 battery pack PAP 20 A1
3 x 150 mm SDS-plus drills Ø 6 / 8 / 10 mm
3 x drill bits Ø 5 / 6 / 8 mm (HSS) with hexago-
nal shanks
4 x 50 mm bits (S2): 5 .5 / PH1 / PZ1 / PZ2
1 x Bit PH2 (50 mm)
1 x Bit T25 (50 mm)
1 x bit extension (hexagonal shank)
1 x bit extension (SDS-plus fitting)
1 carrying case
50g grease
1 set of operating instructions
Technical data
Cordless hammer drill PABH 20-Li B2
Nominal voltage:
Idle speed:
Stroke rate:
Stroke energy:
Max . drill diameter:
Battery pack: PAP 20 A1
Type:
Rated voltage:
Capacity:
Cells:
High-speed charger: PLG 20 A1
INPUT:
Rated voltage:
Rated power
consumption:
20 V (DC)
n 0–900 rpm
0
0–5000 spm
≥ 1 joule
8 mm for metal
10 mm for concrete
16 mm for wood
LITHIUM ION
20 V (DC)
2 Ah
5
230–240 V ~ , 50 Hz
(AC)
65 W
PABH 20-Li B2
