CABLE GLAND DIAGRAMS
M25 - AC INPUT
CLAMPING RANGE: 10-17MM*
30
M25
6.5 Nm
DALI Re-launch
DALI
DMX Re-launch
DMX
2 X M16 DALI/DMX
CLAMPING RANGE: 5-10MM
In case of using smaller outer diameter cable, please
replace the cable gland's internal gasket with the one
attached in the packaging.
*M25 modified clamping range: 7-13 mm
**M32 modified clamping range: 8-14 mm
DALI CONTROL
Connector
Cable ID
ID
Protective Earth
L1
Line1/Line
L2
Line2/Neutral
DA+
DALI+
DA-
DALI-
*+2/-2 available in case of 3
channels
RESPECT THE POLARITY OF THE DALI LINES WHEN USED WITH A CONTROL SYSTEM!
03-75-196 | rev B | 01-2024
36
M32
8 Nm
M32 - DC OUTPUT
CLAMPING RANGE: 13-21MM**
+ + - -
M25
30
M32
36
6.5 Nm
8 Nm
30
M25
6.5 Nm
Ventilation
valve
M16
19
2.5 Nm
Connector
Cable ID
ID
Protective Earth
+1
LED1+ connection
-1
LED1- connection
+2
LED2+ connection*
-2
LED2- connection*
+3
LED3+ connection
-3
LED3- connection
www.schreder.com
M32
42
7.5 Nm
M25 - AC INPUT
CLAMPING RANGE: 13-18MM*
M25
34
M32
42
5.5 Nm
7.5 Nm
M32
M16
23
M25
34
2.5 Nm
5.5 Nm
M25
M16
23
2.5 Nm
DALI Re-launch
DMX Re-launch
2 X M16 DALI/DMX
CLAMPING RANGE: 5-10MM
In case of using smaller outer diameter cable, please
replace the cable gland's internal gasket with the one
attached in the packaging.
*M25 modified clamping range: 7-13 mm
**M32 modified clamping range: 8-13 mm
Connector ID
Cable ID
CM
Surge protection
L1
Line1/Line
L2
Line2/Neutral
PE
Protective Earth
DA+
DALI input+
DA-
DALI input-
24V
24V aux. source
DALI re-launch
DA+
input+
DALI re-launch
DA-
input-
M32 - DC OUTPUT
CLAMPING RANGE: (13)15-21MM**
36
M32
M32
8 Nm
M32
36
30
M25
8 Nm
M25
6.5 Nm
30
M25
M16
6.5 Nm
5.5 Nm
DALI
M16
DMX
2.5 Nm
Connector ID
Cable ID
Protection Earth for
LUM
LED module
LED1+ connection
V1+
V1-
LED1- connection
V2+
LED2+ connection**
V2-
LED2- connection
V3+
LED3+ connection**
V3-
LED3- connection
Thermal protection
OTP
input
**Support common anode output
connection
42
7.5 Nm
42
7.5 Nm
34
5.5 Nm
34
Ventilation
23
valve
2.5 Nm
23
3/6
