ENG INSTALLATION INSTRUCTIONS
DEU INSTALLATIONSANLEITUNG
FRA INSTRUCTIONS DE MONTAGE
SRP UPUTSTVA ZA INSTALACIJU
02
Pending
A - PRODUCT OVERVIEW
B - MOUNTING OPTIONS
14.5 ( 2 X )
9.0 ( 4 X )
21.5
02-24-998 | DOC-0019186 rev E | 06-2022
E
C
ITA
ISTRUZIONI DI INSTALLAZIONE
POL INSTRUKCJE MONTAŻU
SPA INSTRUCCIONES DE INSTALACIÓN POR INSTRUÇÕES DE INSTALAÇÃO SWE INSTALLATIONSANVISNING
تعليامت الرتكيب
AR
PROJECT NUMBER
IEC
00
E
C
EN60598
532mm / 20.94"
82 / 3.23"
200 / 7.87"
B
NLD INSTALLATIE INSTRUCTIES
DAN INSTALLATIONSVEJLEDNING
RUS Инструкции по установке
RON INSTRUCŢIUNI DE INSTALARE
A3
CxS
B
0.23m²
530 / 20.8"
Mounting to vertical or horizontal surface:
- 4x min M10 - M12
- 2x min M12 - M14
- 4x M8 + 1x M20
www.schreder.com
OMNISTAR
KIT ECO
HUN TELEPÍTÉSI ÚTMUTATÓ
CHI
UKR Інструкції з монтажу
220-240V
620W
25.6kg
50Hz
安装说明
IP
IK
66
08
1/5
Werbung
Verwandte Anleitungen für Schreder OMNISTAR KIT ECO
Inhaltszusammenfassung für Schreder OMNISTAR KIT ECO
- Seite 1 - 2x min M12 - M14 - 4x M8 + 1x M20 532mm / 20.94” 14.5 ( 2 X ) 82 / 3.23” 200 / 7.87” 9.0 ( 4 X ) 21.5 02-24-998 | DOC-0019186 rev E | 06-2022 www.schreder.com...
