Assembly Instructions
◆ Handlebar Installation(4mm Hex Wrench)
Step 1:
Loosen the bolts on your bike stem.
Step 2:
Center your handlebars and rotate them to align to the marking pointed to in the
below image.
Step 3: Tighten bolts to handlebar stem, but don't tighten completely as you may want
to further adjust the angle later to align more precisely. Test the positioning, and
adjust the handlebar to your preferred angle. After determining the best position,
completely tighten all the bolts on the stem.
NOTICE:
In addition to angle, the height of the handlebar can be adjusted by
adding or removing the headset spacers if needed. For those without experience,
we recommend having a professional make such adjustments for safety reasons.
◆ Rear Rack Installation (4mm Hex Wrench)
The rear rack comes loosely attached to the bike, but has not yet been fully secured.
Step 1:
Remove the bolts with washers located a couple inches behind the seat post.
Step 2:
Place the rack down and adjust placement until the holes on the end are aligned,
and screw the bolts back in. Make sure the washer is on top of the rack, rather
than underneath, as shown in the below image.
Step 3:
Tighten the eyelet bolts on both sides of the rear rack to the frame.
◆ Front Wheel Installation
Step 1: After tightening the rear rack, lay a mat down to protect both bike and floor from
scratches. Next, carefully flip your bike upside down for the front wheel
installation.
7
