• Turn off the power supply and disconnect all connection cables from the device
and the power plug from the power socket.
• Now press the rear of the fuse holder in somewhat with a suitable straight-edge
screwdriver and turn it anticlockwise outward one quarter of a turn (bayonet
catch).
• Replace the defective fuse with a new fine-wire fuse (5 x 20 mm) of the same type
and rated current:
T2,0A / 250V (slow burning).
• Rotate the fuse insert clockwise while pressing it back into the fuse holder.
Troubleshooting
By purchasing the power supply you have acquired a product that is reliable and
operationally safe.
However, problems and malfunctions may occur.
For this reason we want to describe how to troubleshoot potential malfunctions:
Do not fail to heed the safety instructions!
Fault
The mains power supply does
not work
Connected consumers do not work Correct voltage set?
Periodically check the technical safety of the device, e.g. check for damage to the
housing etc.
Any other repair work must always be carried out by qualified
experts familiar with the hazards involved and with the relevant
regulations. Unauthorised modifications and repairs of or inside
the device will render the warranty null and void.
22
Possible cause
Do characters appear in the display?
Check the mains voltage (you may also want
to check the mains fuse in the device or the
line circuit breaker).
Correct polarity?
Overload of the power supply?
Check the technical data of the consumers.
Is current limiting active?
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Usage in accordance with intended purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Safety instructions and hazard warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Functional description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Placing the system in operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Series and parallel operation of Output A and B . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Maintenance and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Scope of delivery
Power supply PS 2403 PRO
Operating instructions
Controls
Fig. 1 (fold-out page)
(1) Digital display for output DC voltage in volts (OUTPUT A)
(2) Digital display for output current in amps (OUTPUT A)
(3) Digital display for output DC voltage in volts (OUTPUT B)
(4) Digital display for output current in amps (OUTPUT B)
(5) LED displays for active voltage limiting (CV), over-temperature (TEMP) and
active current limiting (CC) from "OUTPUT B"
(6) Pushbutton for reading the output voltage from "Output C" in the digital display
(3)
(7) Output voltage control for voltages ranging from 3 to 6 VDC "OUTPUT C"
15
