Adjusting the height of seat belts
1. Take out the belts from
2. Pull out the belts of the holes
3. Place back belts in the desired
and are not twisted.
4. Place the belt in the central
softeners. Pull the softeners to make sure they are securely attached.
5. Select the height of the straps according to the child's height (Picture 5). The position of the straps should be at or
slightly above the shoulders of the child. (Picture 5B) Do not use seat belts if the openings for the belts are under the
child's shoulders or if the child is over 18 kg. In this case, use the belt of the car.
Adjust the length of the belt
1. Loosen the belt: Press the button for adjustment of the straps (Picture 6a) and at the same time pull out both
shoulder straps (Picture 6b).
2. Tightening the belt: Place your child in the seat, fasten both belts in the buckle in the center and pull the bar in the
middle of the seat. (Picture 13b).
Adjust the length of the belt
1. Loosen the belt: Press the button for adjustment of the straps (Picture 6a) and at the same time pull out both
shoulder straps (Picture 6b).
2. Tightening the belt: Place your child in the seat, fasten both belts in the buckle in the center and pull the bar in the
middle of the seat. (Picture 13b).
Adjusting of the headrest at 3 positions
down to desired position. Release the button and make sure the headrest is locked. The headrest
lower positin for "Group
Removing the upholstery
1. Remove all belts as shown in Fig. 14
2. Remove the upholstery of the seat and backrest as shown in Fig. 18
"Group l" / 9 to 18 kg. / With ISOFIX and Top tether - Universal use
IMPORTANT: First please check if there are 2 ISOFIX anchorings
seat back and seat cushion, and the user-ready top tether anchoring
Tips: The user-ready tether anchorage
vehicle floor. For details you could read your vehicle guidelines
Step 1. Press the Release button to release the ISOFIX connectors. Than you can hear an audible sound "click"
Picture 9
Step 2. Push the ISO FIX connectors
10
Tip: If the ISOFIX connectors
green mark on it. Picture 10.1
Step 3. Press the Release button ( Picture 11) and push firmly the child seat towards the car seat backrest.
During this moving the ISOFIX system will tighten the child seat to the car seat backrest and you will hear a
"Click"sound . Ensure that the child seat is firmly pressed to the car seat backrest. Check the ISOFIX release
button again and ensure the latching indication shows GREEN.
Step 4. Grasp the seat body to check the seat if it is fastened tightly or shakes. If the seat shakes and the ISOFIX
connectors are pulled out, please repeat the above steps and install it again.
Step 5 Pull out the Top tether and press the Tether strap release button to extend the strap until it is long enough
to hook the User-ready
car.
Step 6. Hook the Tether strap hook onto the User-ready
the hook, please find one in your favor. Picture 8 ; 12.4
Step 7. Pull the Tether strap on another end back to tighten the Top tether. Picture 12.5
CAUTION: If the Top tether is tightened favorably and correctly, a green mark will turn up on the other end of the
Strap release button, please do check it. Picture 12.6
Step 8. Place the child in the seat. Check the height of the shoulder belts. Make sure the straps are not twisted or
hanging somewhere. Fasten the seat belts on the child, making sure that they are well placed and pull the strap in
the centre of the seat to tighten. ( Picture 13)
