Drehteller montieren
5 Installing the turntable set for Lounge Xtra
5.1 Installing the turntable set without external air connection
Fig. 46: Detaching the cover
Fig. 47: Detaching the rear panel
Fig. 48: Removing the flue pipe bracket
EN 5 | Installing the turntable set for Lounge Xtra
1) Detach cover (if mounted).
2) Lift and detach the rear panel.
3) Remove flue pipe bracket.
