Einstellbare Ausgangstaktraten; Technische Daten - Mutec Smart Clock Bedienungsanleitung

Einstellbare Ausgangstaktraten

Basis WCLK WCLK x 1
32.0 kHz
32.0 kHz
44.1 kHz
44.1 kHz
48.0 kHz 48.0 kHz
64.0 kHz 64.0 kHz
88.2 kHz 88.2 kHz
96.0 kHz 96.0 kHz
128.0 kHz
128.0 kHz
176.4 kHz
176.4 kHz
192.0 kHz 192.0 kHz
WCLK = Word CLock

Technische Daten

GENERATED OUTPUT SAMPLE RATES:
see tables above
OSCILLATOR SPECIFICATIONS
Burned-in, temperature compensated crystal oscillator
(special selected TCXO) housed in a separat metal casing
for excellent protection against external irradiation!
Accuracy: < ± 1 ppm, AES11, grade 1, aligned
Aging tolerance 1st year: max. < ± 0.5 ppm
Jitter: < 100 ps (p-p)
Operating temperature: -10 °C to +60 °C
SYNC OUTPUTS:
8 x Word Clock (BNC), 3.1 V (p-p) @ 75 Ω, ;
Jitter: < 350 ps (p-p); PAL/NTSC video sync @ 75 Ω
1 x AES/EBU (blank frame) sync, transformer balanced, 4.5 V
(p-p) @ 110 Ω, Resolution: 24Bits; AES3-1992 (R1997)
1 x S/PDIF coaxial (Cinch/RCA), unbalanced, 0.5 V (p-p)
@ 75 Ω; Resolution: 24Bits; IEC 60958
1 x S/PDIF optical, Toshiba Toslink
EIAJ RC-5720, IEC 60958
VIDEO GENERATOR SPECIFICATIONS:
PAL or NTSC as composite sync black+burst or
composite sync black
Black+burst levels:
300mV ± 7mV black level
300mV ± 7mV burst level
Adjustable video formats:
PAL 25fps (625 lines)
NTSC 29.97fps (525 lines)
(optional for SMART CLOCK as P/NVSG-01 upgrade,
ordering-no. 8010-005)
12 SMART CLOCK + SMART CLOCK av
WCLK x 2
64.0 kHz
88.2 kHz
96.0 kHz
128.0 kHz
176.4 kHz
192.0 kHz
256.0 kHz
352.8 kHz
384.0 kHz
, Resolution: 24Bits;
TM
WCLK x 4
128.0 kHz
176.4 kHz
192.0 kHz
256.0 kHz
352.8 kHz
384.0 kHz
512.0 kHz
705.6 kHz
768.0 kHz
GENERATED PULL UP/PULL DOWN FREQUENCIES:
(only SMART CLOCK av)
+ 4,1666 % (25/24); - 4,0 % (24/25)
+ 0,1 % (1001/1000); - 0,1 % (1000/1001)
POWER SUPPLY:
Internal power supply, 115 V/230 V (switchable), 50-60 Hz,
power consumption: max. 15 W, removable power cord
(IEC320/C13 aligned)
SYSTEM UNIT COVER SIZES:
Aluminium sheet: 196 mm x 42 mm x 156 mm (W x H x D)
Front panel aluminium anodized: 198 mm x 44 mm x 2 mm
(W x H x D), 7.8”
WEIGHT:
~ 1320g without P/NVSG-01 option
~ 1340 g with P/NVSG-01 option
OPTIONS:
P/NVSG-01, PAL/NTSC video generator upgrade for
SMART CLOCK, ordering-no. 8010-005
MW-01/19, Set of two rack mounting angles,
ordering-no. 8020-005
MW-01/19, Set of two rack mounting angles,
ordering-no. 8020-010
Optical cables in different lenghts from 0.5 m to 20 m
Basis WCLK WCLK x 256
32.0 kHz
8.1920 MHz
44.1 kHz
11.2896 MHz
48.0 kHz 12.2880 MHz
64.0 kHz 16.3840 MHz
88.2 kHz 22.5792 MHz
96.0 kHz 24.5760 MHz
