COMPACT 1.4
EN
Exploded view to the fixing of the brackets
Centring device
Original edging
Cab roof
Exploded view to the fixing of the consoles
Centring device
Upholstery
Flat washer Ø 8 wide-flange
Hexagonal M-H
Flat washer Ø 8
Pressure washer Ø 8
Rubber washer Ø 6
Flat washer Ø 6 wide-flange
Hexagonal M-M
Flat washer Ø 6
M6 Nut
Internal air distribution
6/100x15 screw
panel
Console
12
Rubber washer Ø 7
Fixing support
M8/125 bolt
Hexagonal M-M
6/100x15 screw
®
