Thomas Regout BalanceBox 650-II Installationsanleitung Seite 8

BalanceBox
9 Mount the BalanceBox
Note: 2 middle holes are for secondary fixation.
EN
4x
MINIMUM!
10 Mount 2x screws [D] on the side of the Wall bracket [C] to the BalanceBox
or backward to vertically align it to the wall, tighten both screws [D] min. 10Nm / 7.4 ft-lbs.
[D] 2x
® 650-II
® [A] on the wall using the predrilled holes from step 4. (fasteners not included)
Secondary fixation
8
A (1x)
® [A]. Slide the BalanceBox
A (1x)
® forward
C (1x)
D (2x)
