Common Screen Resolution Aspect Ratios
The following table summarizes common screen resolutions and their corresponding aspect ratios.
Use this table to set the Paper Tablet aspect ratio for your monitor.
Code Name
VGA Video Graphics Array
SVGA Super Video Graphics Array
XGA eXtended Graphics Array
XGA+ eXtended Graphics Array Plus
SXGA Super eXtended Graphics Array
UXGA Ultra eXtended Graphics Array
WXGA Widescreen eXtended Graphics Array
SXGA Super eXtended Graphics Array
HD High Definition (Basic)
HD+ High Definition (Plus)
HD-1080 Full High Definition
WXGA Widescreen eXtended Graphics Array
WSXGA Widescreen Super eXtended Graphics Array
WSXGA+ Widescreen Super eXtended Graphics Array
Plus
WUXGA Widescreen Ultra eXtended Graphics Array
Adjusting Active Areas for Mac OS X
Windows and Mac OS X computers manage screen locations differently. This difference affects the
active areas on Livescribe paper products. If you are using a Mac, you can adjust the active areas to
improve the mapping between Tablet Pages and your monitor.
™
Livescribe Paper Tablet User Guide
Adjusting Active Areas for Mac OS X
Width Height
640 480
800 600
1024 768
1152 864
1280 960
1600 1200
1280 768
1280 1024
1366 768
1600 900
1920 1080
1280 800
1440 900
1680 1050
1920 1200
Aspect ratio
4:3
4:3
4:3
4:3
4:3
4:3
5:3
5:4
16:9
16:9
16:9
16:10
16:10
16:10
16:10
