5.1.2 Adjusting the depth gauge (optional)
1. Press the release button on the side handle.
2. Adjust the depth gauge to the desired drilling depth.
3. Release the release button.
4. Check that the side handle is securely attached.
5.1.3 Removing the chuck
CAUTION
Risk of injury. The depth gauge, if fitted but not used, might hinder the operator.
▶ Remove the depth gauge from the product.
Set the function selector switch to the
1. Disconnect the supply cord plug from the power outlet.
2. Grip the chuck as shown in the illustration and pull the three chuck release rings upwards.
3. Lift the chuck upwards away from the tool.
5.1.4 Fitting the chuck
CAUTION
Risk of injury. The depth gauge, if fitted but not used, might hinder the operator.
▶ Remove the depth gauge from the product.
When changing the chuck, set the function selector switch to this position:
1. Disconnect the supply cord plug from the power outlet.
2. Grip the chuck as shown in the illustration and pull the three chuck release rings upwards.
3. Fit the chuck onto the chuck mount.
4. Rotate the chuck until it engages in position.
5.1.5 Fitting the accessory tool
1. Apply a little grease to the connection end of the accessory tool.
▶ Use only genuine Hilti grease. Use of the wrong grease can result in damage to the tool.
2. Push the accessory tool into the chuck as far as it will go, turning it and applying light pressure until it
engages with an audible click.
3. After fitting the accessory tool, grip it and pull it firmly in order to check that it is securely engaged.
▶ The product is ready for use.
5.1.6 Removing the accessory tool
CAUTION
Risk of injury by the accessory tool! The accessory tool might be hot or have sharp edges.
▶ Wear protective gloves when changing the accessory tool.
▶ Pull the tool lock back as far as it will go and remove the accessory tool.
5.2 Types of work
WARNING
A damaged supply cord presents a hazard! Do not touch the supply cord or extension cord if damaged
while working. Disconnect the supply cord plug from the power outlet.
▶ Check the appliance's supply cord at regular intervals and have it replaced by a qualified specialist if
found to be damaged.
Check extension cords at regular intervals and replace them if found to be damaged.
16 English
3
4
"Chiseling" position for changing the chuck.
4
5
5
.
