To identify the position and function of the
fuses, refer to the information provided under the
lid of the box and on the attached wiring diagram;
the reference letters in the figure correspond to
those shown in the diagram.
Remember that the fuse box contains four spare
fuses.
Replace the blown fuse and refit the cover.
WARnInG
never replace a fuse with a rating other
than that prescribed, in order to avoid
damage to the electrical equipment of
the motorcycle which could lead to a fire.
MAIntenAnce
F1 F2 F3 F4
10A
- 41 -
F5 F6 F7 F8 F9 F10
15A 15A 25A
