SISTEMATICA EASY Benutzerhandbuch Seite 83

The handheld is equipped with 3 LEDs used to indicate the functioning of the system. The various meanings are described in the following table.*
LED OPERATION
Blinks 1 time
GREEN Blinks 6 times
Flashes every 5 sec.
SAFETYPOINT™
PAIRING
YELLOW TILTING HAND
PAGE
CHANGE
Flashes
RED Fixed light
TILTING HAND
BACKLIGHT: activates upon waking from standby (power saving) in low light conditions.
*To find out the meaning of the LEDs on a charging handheld, see p.81
LEDS ON HANDHELD
Fixed light Handheld is outside the SafetyPointPlate range when a SafetyPoint key is pressed
3 Flash
Fixed light
Blinks 1 time
Blinks 2 times
Fixed light
MEANING
A key is pressed
Lost radio link
Sending radio signal (CloseLink)
PAIRING OK
Out of range of inclination of the handheld
Selection of the 1st page or signals the key pressed is on the 1st page
Selection of the 2nd page or signals the key pressed is on the 2nd page
While I press a key it indicates low battery
While I press a key it indicates dead battery
Calibration mode active
83
