POWER ON
The system consists of a transmitter (HANDHELD) and a receiver
(CONTROLLER).
By pressing START on the handheld, the CONTROLLER exits standby and
establishes radio connection with the handheld (CloseLink).
The system stops when the STOP button or the Emergency Button (if
present) is pressed, or IF the TimeOut has elapsed, or when the radio
connection is lost (CloseLink).
INSTRUCTIONS
1. Power the CONTROLLER paired with the handheld (see PAIRING in case of
failed coupling) and wait a few seconds.
2. Press START on the handheld to enable the CONTROLLER to execute the
commands (START also activates the EO). By not pressing anything, the
system will automatically go into standby after 2 minutes (TimeOut), also
deactivating the EO.
3. Press the desired key on the handheld to activate the output to be
controlled (in standard software the MASTER OUTPUT -MO- is combined
with all the function keys and is activated simultaneously. E.g.: KEY 1 =>
OUT 1+MO) .
4. Press STOP at the end of the activity to close the work session.
SYSTEM
System coding (PAIRING) is necessary to replace a receiver or use it with
a handheld device other than the one it was paired with at the time of
purchase.
For more recent devices please follow the ClassicLine AUTOMATIC PAIRING
procedure:
1. When the receiver is powered, its LED will go from solid GREEN to 5
seconds of flashing YELLOW.
2. Within these 5 seconds, simultaneously press any 3 keys (excluding STOP)
on the handheld until the YELLOW LED flashes 3 times.
3. The TX/RX system will be coupled and this PAIRING will remain valid until
a new one is performed. The verification is carried out by testing the
movements of the system.
It is possible on request to combine multiple handhelds with
the same CONTROLLER, or vice versa.
TUTORIAL PAIRING
QRCode
PAIRING
