Robitronic Avid Bedienungsanleitung Seite 12

9
Ball ends
RA0095 X4
Ball end with socket M3x5mm
Kugelkopf M3x5mm
RA0092 X4
Washer 2mm
Unterlegscheibe 2mm
RA1002 X2
Tie rod for steering 26mm
Spurstange für Lenkung 26mm
RA1003 X4
Tie rod for suspension 30mm
Spurstange für Aufhängung 30mm
RA0600/2 X14
Ball end
Kugelkopf
RA0095
25.5mm
Servo rod (RA1001)
Spurstange für Lenkservo (RA1001)
18.8mm
Front suspension rod (RA1003) X2
Spurstange für vordere Aufhängung (RA1003)
9.7mm
Steering rod (RA1002) X2
Spurstange für Lenkung (RA1002)
20
RA1001
Tie rod for servo 40mm
Spurstange für Lenkservo 40mm
RA0095
RA0092
21
Servo rod (RA1001)
Spurstange Lenkservo (RA1001)
BAG L
RA0092
Front suspension rod (RA1003)
Spurstange vordere Aufhängung (RA1003)
10
RA0095
RA0092
Steering rod (RA1002)
Spurstange Lenkung (RA1002)
RA0095
RA0092
