Operating and safety instructions
EN
USE OUTDOORS ONLY
PLEASE READ INSTRUCTIONS CAREFULLYBEFORE ASSEM-
BLYRETAIN THIS MANUAL FOR FUTURE REFERENCE
IMPORT ANT SAFETY INFORMATION
Please read this user manuał before using this BBQ and keep it safe
for future reference.
Read the following instructions carefully and be sure your BBQ is
properly installed, assembled and cared for. Retain the instructions
for future reference.
Failure to follow these instructions may result in serious bodily injury
and/or property damage.
WARNING - Risk of Suffocation! BBQ's must be used outdoors and
must not use in enclosed areas such as sheds or marquees!
Read the instruction manuał before using the appliance.
WARNING - Accessible parts may be very hot. Keep young children
away.
Wear heat proof gloves whilst operating the appliance.
This appliance must be kept away from flammable materials during
use.
Do not move the appliance during use.
Turn off the gas supply at the gas cylinder after use.
Do not modify this appliance.
If you have any questions concerning assembly or operation, consult
the retailer or Bottled Gas Company.
Always place the appliance and cylinder on fiat level ground.
Never light the appliance with the hood in the closed position.
Your BBQ can be used with gas cylinders between 11 kg and 15 kg.
The maximum size is 310mm (Diameter) x 600mm(Height).
Your BBQ will perform better if propane or LPG mixtures are used.
Butane can be used but because of the power of this appliance the
cylinder may tend to freeze and supply gas at reduced pressures af-
fecting the performance of your BBQ.
The BBQ is supplied with a 27mm clip on 37mbar regulator. Alterna-
tive regulators may be used as long as they are the correct rating for
the BBQ and type of gas used.
When positioning the BBQ the following clearances must be obeyed:
Sides and rear of appliance: 1 METREFROM ANY OBSTRUCTION.
Above the appliance: NO OVERHEAD OBSTRUCTION ARE
PERMITTED.
Please turn off the gas cylinder if gas leak is suspected.
Parts sealed by the manufacturer must not be altered by the user. N
o modifications should be made to any part of this BBQ and repairs
and maintenance should only be carried out by a registered Gas Safe
service engineer.
GENERAL INFORMATION FOR SUCCESSFUL ASSEMBLY
Please read the assembly instructions carefully and follow the safety
precautions. Allow sufficient time for assembly. Before starting as-
sembly, elear an area measuring approximately two to three square
as_derby/sheffield_de_en_revI.indd 5
as_derby/sheffield_de_en_revI.indd 5
metres. Remove the item from the packaging and lay out all of the
parts and any necessary to ols so that they are within easy reach.
Only tighten all of the screw connections firmly when you have fin-
ished assembly or are instructed to within the manuał. Otherwise
this can result in unwanted tension and in stability.
CONNECTING THE GAS CYLINDER
GAS SUPPLY INFORMATION
This appliance is only suita ble for use with low pressure Butane, Pro-
pane, or LPG mixtures, fitted with the appropriate low-pressure reg-
ulator via a flexible hose. The hose should be secured to the regulator
and the appliance with hose elips. This BBQ is set to operate with a
28 mbar regulator when used with Butane gas, a 37 mbar regulator
when used with Propane gas, and 30 or 50 mbar for LPG mixtures.
Please consult your local bottled gas dealer for information regard-
ing a suita ble regulator for the ga s cylinder, and BBQ.
REGULATOR AND HOSE
This BBQ is provided with a 27mm clip on 37 mbar regulator, suitable
for Calor Patio gas, Flogas Leisure gas, BP Gaslight and similar.
Replacement regulators are available from your equipment retailer
or an authorised bottled gas stockist. Use only regulators and hoses
approved for bottled gas at the above pressures. The life expectancy
of the regulator is estimated as 1 O years. It is recommended that
the regulator should be changed within 10 years of the date ofman-
ufacture.
The use of the wrong regulator or hose is dangerous, always check
that you have the correct items before operating the BBQ.
The hose used must conform to the relevant standards for the coun-
try of use. The length of the hose must be a maximum of 1.5 metres.
Worn or damaged hoses must be replaced.
Ensure that the hose is not o bstructed, kinked or in contact with any
part of the BBQ other than at its connection.
GAS CYLINDER
The gas cylinder should not be dropped or handled roughly. Ifthe
appliance is not in use, the cylinder must be disconnected. Replace
the protective cap on the cylinder after disconnecting the cylinder
from the appliance.
Cylinders must be stored outdoors in an upright position and out
of the reach of children. The cylinder must never be sto red where
temperatures can reach over SO O C. Do not sto re the cylinder near
flames, pilot lights or other sources ofignition. DO NOT SMOKE NEAR
THE CYLINDER(S).
This BBQ is designed for use outdoors only, away from any flamma-
ble materials. It is important that there are no overhead obstructions
and that there is a minimum distance of 1m from the side and rear
of the appliance. It is important that the ventilation openings of the
appliance are not obstructed. The BBQ must be used on a level, sta-
ble surface.
The appliance should be protected from direct draughts and should
be positioned or protected against direct penetration by any trick-
ling water ( e.g. rain).
5
