HOW TO USE THE ROTISSERIE
- impale the meat to be cooked on the spit and fix it in the centre
using the two forks provided;
- insert the tip of the spit into the rotation hub on the frame (see
fig. 6);
- unscrew the handle from the spit;
- place the spit support frame in the central runner of the oven,
at the same time inserting the rotation shaft into the motor hub
(see fig. 6);
- place the drip tray on the bottom runner of the oven and pour
a little water into it;
- switch on the heating element;
- close the door gently;
- baste the meat from time to time. When it is cooked, remove
the frame from the motor hub and screw the handle back on to
the spit.
OVENS WITH THERMOSTAT
If cooking temperatures are not as set, call in an engineer to
check the thermostat.
USE OF SINGLE-CONTROL END OF COOKING TIMER (WITH-
OUT CLOCK) (fig. 8)
This allows the cooking time to be programmed.
Operation:
- Move the knob to the desired cooking time (120 mins max.).
- Choose the temperature using the thermostat knob and move
the selector knob to the required cooking method.
- When the programming knob is at the 0 position the oven will
switch itself off. This is automatic.
- Move the thermostat knob back to symbol .
- Move the selector knob to symbol 0.
N.B. If the timer is not used, the oven programming knob is to
be set to the manual position
USE OF THE ELECTRONIC TIMER (fig. 9)
This allows the start time and cooking duration time to be pro-
grammed.
If food does not need to be watched, this timer can be selected
even when the user is absent. Soon after installation and at any
electrical supply cut-outs the display flashes; the clock must
then be synchronized again to allow programming.
SETTING THE TIMER TO THE CURRENT TIME
- The current time is set by pressing the 2 buttons (
and
) and the "+" or "-" button at the same time. Any
TIME
STOP
previous programmes are cancelled and the
flashes.
NOTE: when the
symbol is flashing the oven cannot be
AUTO
used manually.
"+" AND "-" BUTTONS
- Pressing the "+" or "- "buttons makes time go up or down at
variable speed according to how long the button is pressed
for.
MANUAL USE
- Press the
button: the
permanently on) the
symbol lights up and the oven can be
used by adjusting the thermostat knob and the selector switch
according to the instructions given in the manual.
AUTOMATIC OPERATION WITH END OF COOKING AND
DURATION TIMERS
- Let's use an example: it is 9:25 am; you want the oven to switch
on at 11 am and switch off at 12 pm (cooking time 1 hour).
- Press the
COOKING DURATION
"+" button until it shows 01.00, adjust using "-" button if neces-
and
symbols come on permanently.
sary. The
AUTO
- Press the
END OF COOKING
"+" button until it shows 12.00. The
symbol remains permanently on.
AUTO
.
AUTO
symbol goes out (if flashing or
AUTO
button and within 5 seconds press
button and within 5 seconds press
symbol goes out but the
- Move the oven thermostat knob to the desired temperature,
and the selector switch to the required cooking method; the
red warning light comes on the oven light comes on and the
timer is ready to start: at 11am the oven will come on auto-
matically and the
- When cooking is over (12 am) the
symbol goes out and a buzzer sounds; to turn off the buzzer
press any button.
- Move the thermostat and selector knob to the OFF position.
SEMI-AUTOMATIC OPERATION WITH COOKING DURATION
SELECTION
- Let's take an example: it is 11:35 am and you want the oven to
stay on for 25 minutes from now on.
- Press the
the "+" button until it shows 00.25, adjusting the time with the
"-" button if necessary. The
permanently.
- Turn the oven thermostat knob to the desired temperature and
the selector switch to the required cooking method; the red
warning light comes on, the oven light comes on and the oven
starts to operate.
- After 25 minutes the oven and the
symbol flashes and the buzzer tells you that cooking is over:
to turn off the buzzer press any button.
- Then move the oven thermostat knob and the selector switch
to the OFF position.
MINUTE MINDER
- Press the
using the "+" or "-" button.
- The
BELL
- When the pre-set time is over, the buzzer sounds and the
symbol goes out.
BELL
BUZZER
- The buzzer sounds at the end of a programme and lasts for a
maximum of 7 minutes.
- To turn it off, press any button.
- Pressing the "-" button without having previously selected a
function the frequency of the signal changes. A selection from
3 possibilities can be made. The selected signal is audible as
long as the "-" button is pressed.
STARTING AND CHECKING A PROGRAMME
- The programme starts after about 4 seconds of it being set.
- The set programme can be checked at any point by pushing
COOKING
the corresponding buttons.
PROGRAMMING ERRORS
symbol
- Example: at 12:15 pm a
is set and a
- The programme error can be rectified by changing the dura-
tion or the end of cooking time, or by pressing the
button and programming again.
- If there is a programming error the oven will not come on.
ANNULLING A PROGRAMME
- A programme can be cancelled by pressing the
button and then the "-" button until the display shows
RATION
0.00.
IMPORTANT:
AT THE END OF EVERY PROGRAMMED COOKING OPERA-
TION YOU ARE ADVISED TO PRESS THE
ERWISE THE OVEN CANNOT BE OPERATED MANUALLY.
GENERAL PRECAUTIONS
- Always disconnect the power supply before any work inside
the oven or where live parts may be accessed.
- Never use the warming compartment for storing inflammable
liquids or items which do not withstand heat, such as wood,
paper, aerosol cans, matches, etc.
- Make frequent checks on the rubber connection hose, ensur-
ing that it is well away from hot surfaces, that there are no
sharp bends or kinks, and that it is in good condition. The
14
For the user
symbol will light up.
AUTO
button and within 5 seconds press
COOKING DURATION
AUTO
button and choose the desired time
MINUTE MINDER
symbol lights up when the minute minder is in use.
COOKING DURATION
is programmed in at 12:30 pm.
END OF COOKING
symbol flashes, the
and
symbols light up
symbol go out. The
AUTO
time of 30 minutes
MANUAL
COOKING DU-
BUTTON, OTH-
