SSS Siedle Compact CV 850-1-02 E Produktinformation Seite 5

English
Application
Siedle Compact video door station
in bus technology with the func-
tions calling, speech, vision and door
release, as a replacement device for
the door station in the Siedle Basic
video set SET CVB 850-...
Number of integrated call buttons:
1–2
Performance features:
• Integrated camera with automatic
day/night switchover, LED lighting
and 2-stage heating
• Integrated door loudspeaker
• Adjustable voice volume
• Number of integrated call buttons:
1 (CV 850-1-02), 2 (CV 850-2-02)
• Acoustic button acknowledgement
can be activated
• Backlit nameplates exchangeable
from the front
• for surface mounting with brushed
stainless steel panel
Application
The door station is intended exclu-
sively for Basic sets. Any other appli-
cation is deemed not in accordance
with its intended use and exonerates
the manufacturer from any liability.
Electrical voltage
Mounting, installation and servicing
work on electrical devices may only
be performed by a suitably qualified
electrician.
Electrostatic charging
As a result of electrostatic charging,
direct contact with the circuit board
can result in destruction of the
device. Direct contact with the circuit
board must therefore be avoided.
In the case of video systems, the fol-
lowing mounting situation must be
avoided at all costs:
• direct backlight
• direct sunlight
• very bright image backgrounds
• highly reflective walls opposite the
camera
• lamps or direct light sources
Scope of supply
• CV 850-...-02
• Siedle screwdriver
• This product information
Dismantling / Mounting
1 Unscrew the front of the housing.
To do this, release the Siedle screw
on the underneath of the housing.
Hinge the front of the housing
forward.
2 Release the connections, remove
the rubber plugs in the two upper
openings, unscrew the base plate
of the circuit board and exchange.
Assembly takes place in reverse
sequence. (1:1 exchange)
3 The pick­up angle of the camera
can be mechanically preadjusted on
the vertical and horizontal by appr.
30° depending on the mounting
situation. To change the pick­up
direction of the camera, it can be
positioned in the required direction.
To change the pick­up direction,
loosen the two cross­head screws
slightly. Position the camera in the
required direction. Then fix the
required position using the two
cross­head screws.
4 Depending on the installation
environment, it may be necessary
to change the door station speech
volume in order to permit clear
speech transmission.
5 Hook the front of the housing
onto the base plate at the top and
close. Tighten the screw on the
underneath of the housing.
Lettering
6 Open the nameplate from the
outside, for example using a flat
bladed screwdriver, and carefully
remove the inscription insert. To
insert the nameplate, lock into place
by exerting light pressure.
Terminal assignment
TaK, TbK In-Home bus camera
branch
Tö, Tö Relay contact door
release
Commissioning
Installation, commissioning and
programming are described in
the product information sheet for
SET CAB/CVB 850-...
Specifications
Colour system: PAL
Image pick-up: CMOS sensor 1/3"
756 x 504 Pixel
Resolution: 550 TV lines
Lens: 3,7 mm
Pick-up angle: horizontal appr. 65°,
vertical appr. 50°
Mechanical adjustment range:
30° horizontal/vertical
Operating voltage: via In-Home bus
Contact type: contact 24 V, 2 A
Protection system: IP 54, IK 8
Ambient temperature:
–20 °C to +40 °C
Dimensions (mm) W x H x D:
82 x 226 x 35
5
