FREQUENCY GROUP CONTENTS
Groups 1–9*
Group 1 complies with the German RegTP regulations for public users ("Nutzergruppe 4"). It
can also be used in Sweden
Groups 2–8 are for fixed indoor installations ("Nutzergruppe 5") in Germany (TV Chan-
nels 62–63).
Group 9 is limited to frequencies between 800.100 MHz and 819.900 MHz. (Due to Dan-
ish regulations, these frequencies are centered on 0.1 MHz frequencies).
Groups 10–25*
Groups 10–12 provide the maximum number of compatible frequencies between 800
and 830 MHz.
Groups 13–15 complies with the new German RegTP regulations for public users ("Nut-
zergruppe 4") in the new legal frequency range up to 814 MHz.
Group 16 complies with the new German RegTP regulations for users of "Nutzergruppe
3A" in the new legal frequency range up to 814 MHz (TV Channels 62–63).
Group 17 complies with the new German RegTP regulations for users of "Nutzergruppe
3B" in the new legal frequency range up to 814 MHz (TV Channels 62–63).
Group 18 complies with the new German RegTP regulations for users of "Nutzergruppe
3C" in the new legal frequency range up to 814 MHz (TV Channels 62–63).
Group 19 complies with the new German RegTP regulations for users of "Nutzergruppe
3D" in the new legal frequency range up to 814 MHz (TV Channels 62–63).
Group 20 complies with the new German RegTP regulations for broadcast users of "Nut-
zergruppe 2" in the new legal frequency range up to 814 MHz (TV Channels 62–63).
Group 21 complies with the new German RegTP regulations for broadcast users of "Nut-
zergruppe 1" in the new legal frequency range up to 814 MHz (TV Channels 62–63).
Groups 22 and 23 are preferred for use in Sweden and provide the maximum number
of compatible frequencies between 800 and 814 MHz.
Groups 24 and 25 are preferred for use in the Netherlands and provide the maximum number
of compatible frequencies between 806 and 814 MHz (European TV channel 63).
*Please contact your national frequency authority to get information on the available legal frequencies for your
area and legal use of the equipment.
SYSTEM COMPATIBILITY GUIDE R2 FREQUENCY BAND
Channel Group 1 Group 2
1 802.325 802.050
2 803.075 802.675
3 804.800 804.425
4 805.200 805.050
5 806.850 807.050
6 809.150 808.550
7 810.150 810.550
8 812.800 811.050
9 819.100 812.300
10 819.600 814.675
11 821.150 815.300
12 821.750 816.425
13 822.950 819.800
14 825.150 821.550
15 826.000 822.800
16 827.100 823.800
All manuals and user guides at all-guides.com
TABLE 2
Group 3 Group 4
802.300 803.050
803.925 804.550
804.925 805.300
806.175 808.175
808.175 808.800
808.675 811.300
810.550 812.050
812.175 812.550
813.175 813.550
814.425 814.175
817.925 816.550
819.175 817.550
819.675 821.275
821.175 822.800
821.800 823.300
823.425 826.550
8
(
800 – 830 MHz)
Group 5 Group 6 Group 7
803.625 803.375 802.425
804.125 804.500 803.300
805.000 806.875 803.675
807.125 808.000 806.675
808.500 808.875 807.125
808.875 810.125 808.925
809.625 810.625 809.425
811.000 811.875 810.425
811.625 812.875 813.425
816.375 814.625 813.925
818.750 818.125 815.925
819.375 819.500 816.800
820.875 820.125 818.175
821.375 822.625 818.675
822.125 823.125 820.925
822.625 823.875 821.675
Group 8
802.300
803.050
804.050
806.550
807.550
808.300
808.800
809.550
810.550
811.300
811.800
813.300
819.300
819.800
821.800
822.175
