CONTROLLER
Segnale Comando Ventilatore
Fan Drive Signal
Signal de Commande Ventilateur
Steuergerät Signal
Senãl de Commando Ventilador
Fan Drive Signal
PE L N
4
PE
PE
L
N
20
Accessorio non incluso
Not included accessories
Accessoires non inclus
Zubehör nicht im Preis enthalten
Accessorios no incluidos
Accessoires niet inbegrepen
0 Vdc
>1 Vdc
10 Vdc
5 6 7 8 9 10 11 12
SCHEDA ECM
= Fan OFF / Fan OFF / Ventilateur OFF
Ventilator OFF / Ventilador OFF / Fan OFF
= Fan ON / Fan ON / Ventilateur ON
Ventilator ON / Ventilador ON / Fan ON
= Velocità massima / Maximum speed
Vitesse maximale / Höchstgeschwindigkeit
Máxima velocidad / Maximale snelheid
13 14 15
MFC
LEGENDA Scheda BLAC:
BLAC = Scheda
elettronica Inverter
T1 = Collegamento
protezione termica motore
0-10Vdc = Segnale ingresso
U/V/W = Collegamento motore
DFS-/DFS+ = Segnal digitali
CONTROLLER = Regolatore
WH = Bianco
RD = Rosso
BK = Nero
BU = Blu
ECM

ELECTRONIC BOARD

0Vdc
10Vdc
WH
RD
BU
BK
BLAC Board LEGEND:
BLAC = Inverter circuit board
T1 = Motor fan
thermal protector connection
0-10Vdc = Input signal
U/V/W = Motor fan connection
DFS-/DFS+ = Digital fault signals
CONTROLLER = Controller
WH = White
RD = Red
BK = Black
BU = Dark Blue
UNT-SVX26M-XX
