3. Tighten the knobs onto the bolts.
4. Do the same operation on the other side.
3.4

INSTALL THE GRASS CATCHER

Figure 4
1. Remove the mulch plug.
2. Remove the side discharge chute.
3. Open the rear discharge flap and hold it.
4. Hold the the grass catcher by its handle and engage the
hooks on the door rod.
5. Close the rear discharge flap.
3.5

INSTALL THE MULCH PLUG

Figure 5.
1. Remove the grass catcher.
2. Open the rear discharge flap and hold it.
3. Hold the mulch plug by its handle and fit it in the
discharge chute.
4. Close the rear discharge flap.
3.6 INSTALL THE SIDE DISCHARGE
CHUTE
Figure 6
CAUTION
When you use the side discharge chute,
• Do not install the grass catcher.
• Keep the mulch plug installed.
1. Open the side discharge flap and hold it.
2. Line up the recesses of the side discharge chute below the
pivot.
3. Close the side discharge flap.
3.7 SET THE BLADE/CUTTING
HEIGHT
The machine can be set to different blade/cutting heights.
Figure 7
1. Pull the height adjustment lever rearward to increase the
blade/cutting height.
2. Push the height adjustment lever forward to decrease the
blade/cutting height.
3.8

INSTALL THE BATTERY PACK

Figure 8
English
• If the battery pack or charger is damaged, replace the
battery pack or the charger.
• Stop the machine and wait until the engine stops before
you install or remove the battery pack.
• Read, know, and follow the instructions in the battery
and charger manual.
USE ONLY 24V BATTERY. DO NOT USE DUAL-
VOLTAGE 24/48V BATTERY.
Both batteries should be installed into the compartments in
order to start the machine.
1. Open the battery flap.
2. Align the lift ribs on the battery pack with the grooves in
the battery compartment.
3. Push the battery pack into the battery compartment until
the battery pack locks into place.
4. When you hear a click, the battery pack is installed.
5. Do the same operation with the other battery.
6. Close the battery flap.
The motor starts only when you put in the safety key.
3.9

REMOVE THE BATTERY PACK

Figure 8
1. Open the battery compartment flap
2. Remove the safety key.
3. Push and hold the battery release button.
4. Remove the battery pack from the machine.
4

OPERATION

Wear eye protection during operation.
4.1

START THE MACHINE

Figure 9
1. Put in the safety key.
2. Push and hold the start button.
3. While you hold the start button, pull the bail switch in the
direction of the handle bar.
4. Release the start button to start the machine.
5
WARNING
WARNING
NOTE
NOTE
WARNING
