4.3 Insert the quick release into the front wheel hub axle hole.
Note:There are two springs on the quick release.
2
1
4.4 Install the tire axle into the front fork groove. Note:Make sure
the brake disc is placed between the two brake pads.
4.5 Fix the nut of front wheel quick release with right hand and
screw the quick release handle clockwise with left hand.
4.6 Fold the quick release handle to fix the tire tightly.
Note:Make sure the brake disc of the wheel will not rub the brake
pad when it is rotating under the condition of not taking the brake.
Step 5
Install the front fender and the
headlight
5.1 Install the front fender and headlight on the front fork bridge
with matching bolt and nut.
Light
Bolt
Fender
9
5.2 Screw the nut with wrench to tighten the front fender and the
headlight.
Nut
5.3 loose the bolt with a
wrench to adjust the headlight
angle so the light can
illuminate the road ahead.
Tighten the bolt when the
adjustment is done.
5.4 Connect the headlight cable.
Note:Make the two arrows stay in a line when pushing the connector
5.5 Screw the two bolts to fix the side brace of fender.
1
2
Step 6
Adjust and tighten the handle
stem
Make the handlebar at a 90 degrees angle to the tire and then
screw the two bolts tightly.
1
10
2
