4 Operation – 4.4 Measurements
1
Measuring with rectangular cells with open
lid:
Insert rectangular cells (10, 20, 50 mm)
2
3
9
4 4
• Insert the rectangular cell vertically into the
cell compartment
flush against the left side of the cell holder
at all times
• Measurement starts automatically, and the
measurement result is displayed in the con-
centration measurement overview
7)
5
22
, ensuring that the cell is
8
(see page
Measuring with rectangular cells with open
lid:
Insert 100 mm rectangular cells
(Prove 600 plus)
• Remove the top of the round cell compartment
including the AutoSelector
8
• Insert the 100 mm rectangular cell vertically
into the cell holder
it with both hands on the small edges while
inserting it carefully
• Measurement starts automatically, and the
measurement result is displayed in the con-
9
centration measurement overview
7)
NOTE
Please see Analytical Procedures and Appendices
for detailed measurement procedures.
10
. Make sure that you hold
11
(see page
Version 1.0 – 07/2023
