1. General Information
Always connect the battery first, in order to allow the Controller
•
to recognize system voltage
Use a 12V (36 cells) solar array for a 12V system.
•
• Use a 24V (72 cells) solar array for a 24V system.
The BlueSolar PWM Charge Controller series uses Pulse Width Modulation (PWM)
charge voltage control combined with a multistage charge control algorithm.
2. Features
Three stage battery charging [bulk – absorption – float]
•
Battery type: Lead-acid and LiFePO4 (with internal BMS)
•
Protected against over current.
•
Protected against short circuit.
•
Protected against reverse polarity connection of the solar panels and/or battery.
•
Low voltage load disconnect.
•
Temperature protection.
•
3. Installation
Important note: always connect the batteries first.
1
