Marq Ray Tracer X Benutzerhandbuch Seite 9

17-Channel Operation
Channel Function
17 Control Functions
All functions are executed
after 2 seconds.
8-Channel Operation
Channel Function
1 Pan
Tilt 1
2
3 Tilt 2
Dimmer
4
Shutter
5
Automatic Programs
6
(continued)
Value
000–069
070–079
080–089
090–099
100–109
110–119
120–129
130–139
140–149
150–255
Value
000–255
000–255
000–255
000–255
000–007
008–076
077–145
146–215
216–255
000–005
006–015
016–025
026–035
036–045
046–055
056–065
066–075
076–085
086–095
096–105
Description
No function
Reverse Pan
Disable Reverse Pan
Reverse Tilt 1
Disable Reverse Tilt 1
Reverse Tilt 2
Disable Reverse Tilt 2
No function
Pan/tilt reset
No function
Description
Pan angle, 0° (000) to 630° (255)
Tilt Motor 1, 0° (000) to 150° (255)
Tilt Motor 2, 0° (000) to 150° (255)
Dimmer, dark (000) to bright (255). This feature also
affects the automatic programs (Channel 6).
Closed
Strobe, slow (008) to fast (076)
Pulse, slow (077) to fast (145)
Random strobe, slow (146) to fast (215)
Open
No function
Automatic Program 1
Automatic Program 2
Automatic Program 3
Automatic Program 4
Automatic Program 5
Automatic Program 6
Automatic Program 7
Automatic Program 8
Automatic Program 9
Automatic Program 10
9
