DMX Functions
You can control Ray Tracer X by linking it to a DMX controller. See the charts of available functions below.
17-Channel Operation
Channel Function
Pan
1
2 Tilt 1
Tilt 2
3
4 Dimmer
5 Shutter
LED 1 Dimmer
6
7 LED 2 Dimmer
LED 3 Dimmer
8
9 LED 4 Dimmer
LED 5 Dimmer
10
11 LED 6 Dimmer
LED 7 Dimmer
12
13 LED 8 Dimmer
Automatic Programs
14
Value Description
000–255
Pan angle, 0° (000) to 630° (255)
000–255 Tilt Motor 1, 0° (000) to 150° (255)
000–255
Tilt Motor 2, 0° (000) to 150° (255)
000–255 Dimmer, dark (000) to bright (255). This feature also
affects the automatic programs (Channel 14).
000–007 Closed
008–076 Strobe, slow (008) to fast (076)
077–145
Pulse, slow (077) to fast (145)
146–215 Random strobe, slow (146) to fast (215)
216–255 Open
000–255
LED 1 dimmer, dark (000) to bright (255)
000–255 LED 2 dimmer, dark (000) to bright (255)
000–255
LED 3 dimmer, dark (000) to bright (255)
000–255 LED 4 dimmer, dark (000) to bright (255)
000–255
LED 5 dimmer, dark (000) to bright (255)
000–255 LED 6 dimmer, dark (000) to bright (255)
000–255
LED 7 dimmer, dark (000) to bright (255)
000–255 LED 8 dimmer, dark (000) to bright (255)
000–005 No function
006–015 Automatic Program 1
016–025 Automatic Program 2
026–035 Automatic Program 3
036–045 Automatic Program 4
046–055 Automatic Program 5
056–065 Automatic Program 6
066–075 Automatic Program 7
076–085 Automatic Program 8
086–095 Automatic Program 9
096–105 Automatic Program 10
106–115 Automatic Program 11
116–125 Automatic Program 12
7
