Interlock of store functions
The store functions for switch and control values can be interlocked with the selector switch positions
3 to 6. An unwanted change of stored values is avoided.
Pressing the button at the module unless the green LED blinks (after approx. 10 sec.)
•
The red LED indicates the actual adjustment:
•
- red LED ‚OFF' indicates the possibility of a storage
- red LED ‚ON' indicates that a storage is not possible (interlocked
With a short push of the pushbutton at the module the respective selection can be made.
•
Pressing the button at the module continuously unless the green LED stops blinking (approx. 10 secs.):
•
storage process is finished
If during the adjustment one of the pushbuttons (T1/T2) is pressed, the adjustment mode is left without storage and
the previously selection is maintained.
Accessories:
Sensors
Light and motion sensor
Light sensor
Surface mounting on the ceiling or
with lamp clips on fluorescent lamps.
Mounting to a wall-recessed VDE
or BS-1-gang box into the ceiling.
Manual, Technical data and dimensions of the sensors may be observed.
LBS/d
51.21.031
LS/d
51.21.032
Design 1
LBS/d 51.21.031
LS/d 51.21.032
LB/db
51.21.038
DALI Dim/Converter Control NV
LBS/de
51.21.033
LS/de
51.21.034
Mounting with 2 screws to
lighting fixtures or ceilings.
Integration in a wall-recessed downlight
housing to be swivelling mounted to the ceiling.
Error and technical alterations reserved
16/16
Design 2
LBS/de 51.21.033
LS/de 51.21.034
LB/dk
51.21.039
08.05.2007 1v4
