Step 3: Install the keyed connector of the KMTC speaker's swivel assembly into the keyed socket of the
bracket assembly. The front of the keyed connector should be fl ush with the keyed socket.
Step 4: Install the two swivel levers, adjusting them to be loose (open) when the lever is parallel to the tube,
then secure the bracket gate to the enclosure using the included thumb nuts. When the swivel levers are
locked in place, or closed, the bracket rotation assembly will be clamped tight. With the swivel levers open,
fi nish by tightly securing both thumb nuts. You may need to retighten one after tightening the other.
1
swivel lever
5
keyed connector
keyed socket
2
bracket gate
3
thumb nuts
To mount the enclosure
without swivel adjustment, use
the included socket-head cap
screws to secure the bracket
gate instead of the swivel
levers.
