MODEL:
Authorized KICKER Dealer:
Purchase Date:
Serial Number:
The KICKER KMTC Marine Tower Systems are the perfect way to bring your music out into the marine or
power sports environment. The KMTC9 and KMTC11 come loaded with KICKER KM LED speakers. The
injection-molded ABS enclosures are UV treated, splash resistant, and weather resilient. Mount the KMTC
Marine Tower Systems in your boat or get creative with a pair of them in the garage, on your 4x4 or Side-by-
Side's roll bars, or in any other bar-mounted application.
Model:
Woofer [in, cm]
Horn Loaded Compression Driver [in,mm]
Compression Driver Voice Coil Diameter [in,mm]
Dome Material
Rated Impedance [Ω]
Sensitivity [1W, 1m]
Frequency Response [Hz]
Peak Power Handling [ Watts]
Recommended Amplifi er Power [Watts RMS]
Enclosure Diameter/Width [in, cm]
Enclosure Depth [in, cm]
Enclosure Height (from bottom of roll bar) [in, cm]
Enclosure Height (bracket top to enclosure bottom) [in, cm]
High Pass [dB], at Frequency [Hz]
INSTALLATION
IMPORTANT: You must apply a thin layer of the included anti-seize compound to ALL threaded fasteners
before installation.
Before you begin: Determine the location and placement of the KMTC Marine Tower System onto the
pipe or tube to which you are mounting. Spreading the KMTC Marine Tower System apart will provide better
stereo performance, and is usually preferable. When determining the best locations for mounting, be careful
to look for obstacles or obstructions that could complicate mounting the KMTC. Please keep in mind the
routing of your speaker wires as this can affect where you fi nally mount your cans. If routing speaker wire
through tubing, drill a 9/16" size hole in the bar for a wire grommet before mounting.
Step 1: Position the KMTC lower mounting brackets around the pipe or tubing to which you will be
mounting, then use the included socket-head screws to secure the upper mounting brackets to the bracket
assembly (Fig. 1). Use the screw size best suited for your application. Make sure the bottom bolts (Fig. 2 -
1-1/2" in length) are tight. Kicker recommends adding medium strength (blue) thread locker to these bottom
bolts before installation to prevent them from backing out over time.
2
KICKER Marine Tower Systems
Owner's Manual
KMTC9 | KMTC11
KMTC9
9, 23
1, 25
1-3/8, 35
Titanium
4
92 dB
20-20,000
600
150–300
9-13/16, 24.9
10-7/8, 27.7
11-9/16, 29.4
13-9/16, 34.4
12db/oct, 2,500 Hz 12db/oct, 2,500 Hz
KMTC11
11, 28
1, 25
1-3/8, 35
Titanium
4
93 dB
20-20,000
600
150–300
11-7/8, 30.2
12-11/16, 32.3
13-5/8, 34.6
15-9/16, 39.6
