2 General product description

Labmax eco is our sophisticated dispensing system which fulfills increasing re-
quirements in laboratories. It consists of high precision components and extreme
robust materials "made in Germany".
Labmax eco is an exclusive instrument with 0% loss of reagent due to air-purging
and draining within a closed circuit. The valve block is 360° rotatable; therefore
the label of the bottle is always visible for your additional safety. Labmax has our
unique 100 % drip free system for your safety at work: just turn the discharge tube
at 180 ° to drain it and avoid further uncontrolled flow of liquid!
Labmax eco is fully autoclavable at 121 °C and can be completely disassembled
for cleaning. Each device is tested individually and delivered with conformity certi-
ficate.

3 Commissioning

First attach the discharge tube (7) to the valve block (16)
and then clip on the protective sleeve (6). Make sure it
fits tightly!
Attachment of suction tube
Shorten suction tube to desired length and put it into
the smaller (17) socket of the bottom part of the instru-
ment. Check for the proper length of the suction tube (it
should reach the bottom of the bottle).
The reflux tube is already attached to the bigger socket (18).
17
18
17
