Taurus Elite Smith Machine Montageanleitung Seite 24

7.2 Teileliste
Nr. Bezeichnung (ENG)
1 Left upright
2 Right upright
3 Transverse connecting frame
4 Barbell set
7 Guide rod holder
8 protecting rack
9 Guide rod
10 Counter weight
11 Baffl e
12 Locating tube
13 Short hook column
14 Barbell pipe
15 Bearing retaining ring
16 Ring cover
17 Hook column
18 Rod fi xing ring
19 Limiting screw
20 Sliding tube
21 End cap
22 Rubber bushing
23 Protecting jacket
24 Barbell bushing
25 Round pipe plug
26 Protective mats
27 Rubber bumper
28 Rubber mat
29 Limiting bushing
30 Rubber bumper
31 Cable set
32 Bearing sleeve
33 Spring bracket
34 Aluminum pulley
24
Spezifi kation
M10*25*φ8
φ53*φ31*8
φ36*21
φ46*φ38*212
φ45.5*20.5
Φ62*Φ31*25
φ75*φ47.5*13
Φ58*25.4
Smith Machine
Anz.
1
1
1
1
2
2
2
2
2
4
2
6
2
2
22
4
2
2
4
4
6
6
12
4
2
4
2
2
2
4
2
2
