Table 2
Battery
Charging voltage
Weight
Temperatures at which the battery
can be recharged
Charging time for battery capacity,
approx. (At 20°C)
1.5 Ah
2.0 Ah
2.5 Ah
3.0 Ah
4.0 Ah
5.0 Ah
6.0 Ah
8.0 Ah
Number of battery cells
NOTE
The recharging time may vary according to temperature
and power source voltage.
CAUTION
When the battery charger has been continuously used,
the battery charger will be heated, thus constituting
the cause of the failures. Once the charging has been
completed, give 15 minutes rest until the next charging.
4. Disconnect the charger's power cord from the
receptacle.
5. Hold the charger fi rmly and pull out the battery.
NOTE
Be sure to pull out the battery from the charger after use,
and then keep it.
Regarding electric discharge in case of new batteries,
etc.
As the internal chemical substance of new batteries and
batteries that have not been used for an extended period
is not activated, the electric discharge might be low when
using them the fi rst and second time. This is a temporary
phenomenon, and normal time required for recharging
will be restored by recharging the batteries 2–3 times.
How to make the batteries perform longer.
(1) Recharge the batteries before they become completely
exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery. If
you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate, and
the battery life will be shortened. Leave the battery and
recharge it after it has cooled for a while.
CAUTION
○ If the battery is charged while it is heated because it has
been left for a long time in a location subject to direct
sunlight or because the battery has just been used, the
pilot lamp of the charger lights for 1 second, does not
light for 0.5 seconds (off for 0.5 seconds). In such a case,
fi rst let the battery cool, then start charging.
Charger
UC18YFSL
V 14.4–18
kg 0.5
0°C–50°C
min 22
min 30
min 35
min 45
min 60
min 75
min 90
min 120
4–10
○ When the pilot lamp fl ickers (at 0.2-second intervals),
check for and take out any foreign objects in the charger's
battery connector. If there are no foreign objects, it is
probable that the battery or charger is malfunctioning.
Take it to your authorized Service Center.
○ Since the built-in micro computer takes about 3 seconds
to confi rm that the battery being charged with charger
is taken out, wait for a minimum of 3 seconds before
reinserting it to continue charging. If the battery is
reinserted within 3 seconds, the battery may not be
properly charged.

MOUNTING AND OPERATION

Action
Inserting the battery
Removing the battery
Charging
Turning the spotlight on
Changing the angle of the spotlight
Hanging the spotlight for use*
Changing to spot mode
Changing to wide mode
Low battery notifi cation function*
Strobe mode
Selecting accessories
*1
When using the spotlight while it is hung by a hook, hang
it from a stable and sturdy object.
*2
While the light is lit, when the remaining battery becomes
low and there are 10 minutes or less of light-up time
remaining, the LED light repeatedly blinks 3 times once
per minute.
When in Strobe Mode, the low battery notifi cation
function does not activate.
The remaining light-up time varies depending on the
brightness setting of the light and on the type and
condition of the battery, so it is only an estimate.
NOTE
When using a Multi-volt battery, please refer to the
indicator lamp on the battery for the battery remaining
power.
7
English
Figure Page
2-a 2
2-b 2
3 2
4 2
5 3
6 3
1
7-a 3
7-b 3
8 3
2
9 3
