English
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
UB18DH : Cordless Spotlight
To reduce the risk of injury, user must read
instruction manual.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive
2012/19/EU on waste electrical and electronic
equipment and its implementation in
accordance with national law, electric tools
that have reached the end of their life must
be collected separately and returned to an
environmentally compatible recycling facility.
Direct current
Do not stare at operating lamp.
V volts
Keep the light and the object being illuminated
0,2m
at least 0.2 m apart.
W watts
ta ambient temperature
Class III tool
APPLICATIONS
Illumination of work site
SPECIFICATIONS
Model
Voltage
Brightness
LED (white)
3.0 Ah: Approximatery 4.5 hours
High 5.0 Ah: Approximatery 8 hours
8.0 Ah: Approximatery 12.5 hours
3.0 Ah: Approximatery 7 hours
Operating
Medium 5.0 Ah: Approximatery 12 hours
time
8.0 Ah: Approximatery 19 hours
(Using full
3.0 Ah: Approximatery 14.5 hours
charged
Low 5.0 Ah: Approximatery 24 hours
battery)
8.0 Ah: Approximatery 38.5 hours
3.0 Ah: Approximatery 9.5 hours
Strobe 5.0 Ah: Approximatery 15.5 hours
8.0 Ah: Approximatery 25 hours
Battery available for
this tool*
2
Weight*
3
UB18DH
18 V
1050 lm*
1
10 W
Li-ion battery Multi volt type,
BSL18 Series
1.1 kg (BSL1830C)
1.7 kg (BSL36B18)
*1 When in Wide mode and set to High
*2 Existing batteries (BSL3660/3620/3626, etc.) cannot be
used with this tool.
*3 According to EPTA-Procedure 01/2014
NOTE
Due to HiKOKI's continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
CHARGING
Before using the tool, charge the battery as follows.
1. Connect the charger's power cord to the receptacle.
When connecting the plug of the charger to a receptacle,
the pilot lamp will blink in red (At 1- second intervals).
2. Insert the battery into the charger.
Firmly insert the battery into the charger as shown in
Fig. 3.
3. Charging
When inserting a battery in the charger, charging will
commence and the pilot lamp will light continuously in
red.
When the battery becomes fully recharged, the pilot lamp
will blink in red. (At 1-second intervals) (See Table 1)
● Pilot lamp indication
The indications of the pilot lamp will be as shown in
Table 1, according to the condition of the charger or the
rechargeable battery.
Indications of the pilot lamp (RED)
Lights on for
0.5 seconds and off
Before
for 0.5 seconds
charging
(Blinks)
Lights continuously
While
(Lights)
charging
Lights on for
0.5 seconds and off
Charging
for 0.5 seconds
complete
(Blinks)
Lights on for
1 second and off for
Overheat
0.5 seconds
standby
(Blinks)
Lights on for
0.1 seconds and off
Charging
for 0.1 seconds
impossible
(Flickers)
● Regarding the temperatures and charging time of the
battery.
The temperatures and charging time will become as
shown in Table 2.
6
Table 1
Plugged into power
source
—
—
Battery overheated.
Unable to charge.
(Charging will
commence when
battery cools)
Malfunction in
the battery or the
charger
