ARCTIC COMPACT 5-8
temperature.
2
To shorten product cooling down time and
increase productivity, it is advisable to pre-chill
the product to be used in the dispenser.
3
To shorten product cooling down time and
increase productivity, the bowl should be refilled
after the product level drops lower than half and
at the start of each day.
4
The dispenser must be able to emit heat.
In case it seems excessive, check that no
heating source is close to the unit and air flow
through the slotted panels is not obstructed by
wall or boxes. Allow at least 15 cm (6") of free
clearance all around the dispenser.
In any case if the product in the bowls is cold the
unit is running properly.
5
How to reset beverage temperature:to reset
b e v e r a g e t e m pe r a t u r e p l e a s e ap p l y t o a
technician.
The proper temperature is preset at the factory.
5. 3 CLEANING AND SANITIZING
PROCEDURES
Cleaning and sanitizing of the dispenser are
recommended to guarantee the conservation of
the best product taste and the highest unit
efficiency. This section is a procedural guideline
only and is subject to the requirements of the local
Health Authorities.
Prior to the disassembly and cleaning, the
machine must be emptied of product.
5. 3. 1 DISASSEMBLY
ATTENTION
Before any disassembly
procedure make sure that the dispenser is
disconnected from
unplugging it.
1
Remove cover from the bowl.
2
Remove the empty bowl by lifting first its
front side (faucet side) up and off bowl gasket
and/or cleaning
its power source by
(see figure 1).
3
Remove the bowl gasket.
4
Remove the pump impeller from its location.
5
Pinch tube faucet: push the dispensing
handle (1) and take the pinch tube off from its
seat (2) (see figure 2).
6
Gravity faucet: extract the piston and then
remove the dispensing handle (see figure 3).
7
Slide drip tray out and empty it.
12
figure 1
figure 2
figure 3
