1. Sicherheitshinweise zum Betrieb des Gerätes Dieses Gerät erfüllt die EU-Bestimmungen 2004/108/EG (elektromagnetische Kompatibilität) und 2006/95/EG (Niederspannung) entsprechend der Festlegung im Nachtrag 2004/22/EG (CE- Zeichen). Zur Betriebssicherheit des Gerätes und zur Vermeidung von schweren Verletzungen durch Strom- oder Spannungsüberschläge bzw. Kurzschlüsse sind nachfolgend aufgeführte Sicherheits- hinweise zum Betrieb des Gerätes unbedingt zu beachten.
Dies könnte zu einem Kurzschluss und zur Zerstörung des Gerätes führen. 2. Einführung ® 6205 präzisionsgeregeltes Labornetzgerät einer hohen PeakTech Leistungsfähigkeit. verfügt über Konstantspannungsbetrieb, Konstant-strombetrieb, Überspannungsschutz- und Überlastungsschutzfunktion und kann 8 Stunden im Dauerbetrieb unter Volllast betrieben werden. Spannung und Strom-Werte sind linear angepasst. Mit dieser hohen Stabilität ist dieses Netzteil für den Einsatz in Schulen, Ausbildung, Labor, Universität und...
Seite 5
Netzspannungsbuchse: 115/230 V; 50/60 Hz; +/-10% Sicherungsbuchse: 230 V = 3,15 A; 115 V = 6 A Eingangsspannungsumschalter: Wahlschalter für 115 V oder 230 V...
4. Technische Daten Eingangsspannung 115/230 V; 50/60 Hz (umschaltbar); +/-10 % Sicherung 115/230 V; 3,15 A F Ausgangsspannung 0 – 30 V Ausgangsstrom 0 – 5 A Ausgangsleistung 150 W max. Das Labornetzgerät benötigt 30 Minuten Aufwärmzeit, um die nachfolgenden Spezifikationen zu erfüllen.
5. Betrieb des Gerätes 5.1. Einstellen der Ausgangsspannung Schließen Sie das Netzteil an eine Stromquelle. Drücken Sie den Netzschalter [1] ("I"-Position), um die Stromversorgung einzuschalten. Die CV-ANZEIGE [4] und BETRIEBSANZEIGE [2] leuchtet auf und der Spannungswert wird auf dem Display angezeigt. Verwenden Sie den Spannungsregler „VOLTAGE COARSE“...
5.2. Einstellen des Ausgangsstromes 1. Schließen Sie das Netzteil an eine Stromquelle. 2. Siehe Abschnitt „Einstellen der Ausgangsspannung“ Schritt 1 bis 4, um die Ausgangs- spannung auf 2-5 V einzustellen. 3. Drehen Sie den Stromregler „CURRENT COARSE“ [9] und „CURRENT FINE“ [10] gegen den Uhrzeigersinn, um den minimalen Wert einzustellen.
5.3. Auswechseln der Sicherung Achtung: Stellen Sie sicher, dass alle Verbindungen zum Stromnetz getrennt sind, andernfalls besteht die Gefahr eines elektrischen Schlages. 1. Trennen Sie sämtliche Verbindungen und Stromanschlüsse vom Netzgerät 2. Drehen Sie das Gehäuse, damit Sie die Rückseite ansehen können. 3.
1. Safety Precautions This product complies with the requirements of the following European Community Directives: 2004/108/EC (Electromagnetic Compatibility) and 2006/95/EC (Low Voltage) as amended by 2004/22/EC (CE-Marking). To ensure safe operation of the equipment and eliminate the danger of serious injury due to short- circuits (arcing), the following safety precautions must be observed.
2. Introduction ® The PeakTech 6205 is a precision controlled laboratory power supply with high efficiency. It provides constant voltage mode, constant current operation, overvoltage protection and overload protection function and can be operated 8 hours continuously at full load.
Seite 13
3. Controls and descriptions Power-Switch Power Indicator Constant current mode: LED lights in CC-mode Constant voltage mode: LED lights in CV-mode Voltage-Display Current-Display Voltage coarse adjustment Voltage fine adjustment Current coarse adjustment Current fine adjustment Output socket (+) Output socket (GND) Output socket (-) -12-...
Seite 14
Power Input Socket: 115/230V; 50/60Hz; +/-10% Fuse Socket: 230V = 3,15A; 115V = 6A Input Voltage Selector: Selector for 115V or 230V -13-...
4. Technical Specifications Input Voltage 115/230 V; 50/60 Hz (switchable); +/-10% Fuse 115/230 V; 3,15 A F Output Voltage 0 – 30 V Output Current 0 – 5 A Output Power 150 W max. This power supply needs to warm up 30 minutes to meet the specifications. Stability Adjustable voltage output: 1 x 10...
Seite 16
5. Operation 5.1. Setting the Output Voltage Connect the power supply to the power source. Press the POWER SWITCH [1] to “I” position to turn on the power supply. The CV INDICATOR [4] and POWER INDICATOR [2]* will on and the voltage value will be displayed on the display.
Seite 17
5.2. Setting the Output Current Turn on the power supply Refer to Section 5.1 step 1 – 4 to give the voltage around 2-5V. Turn the CURRENT COARSE TUNE KNOB [9] and CURRENT FINE TUNE KNOB [10] anticlockwise reach the minimum current value. Short the + and the –...
5.3. Changing the Fuse Caution: Ensure no power is connected to the power supply; otherwise, will have an electrical shock. Do not over turn the fuse socket, or you will damage the fuse socket. Disconnect all power connection. Turn over the case. Find the fuse socket.
