Operating instructions

Using OSD controller

Setup menu can be accessed and controlled by OSD control joy stick on the rear of cam-
era unit. Five commands are available with the joy stick.

Description of the joystick operation

1. SET Key (●) : Access to the menu or enter the setting. To enter the main menu,
press the Set Key down for about 1.5sec
2. UP/DOWN Key (▲/▼) : Choose the desired sub-menu and to move the cursor up or
down.
3. LEFT/RIGHT Key (◄/►) : Set up the value of the selected menu. Used to adjust the
desired menu selection and to move the cursor left or right.
4. '☟' denotes the long press down straightly for about 2 seconds
Description of the ZOOM&FOCUS adjustment
Works only when OSD Menu is inactive. Set to Pointing Zoom ON for D-Zoom
i
control.
1. ▲ : Zoom In
2. ▼ : Zoom Out
3. ◄ : Focus Near
4. ► : Focus Far

OSD menu startup

Press '☟' (OSD menu SET key) down long to access the setup menu mode.
i Lens Initializing is strongly recommended at the first stage of setup menu control.
ZOOM/FOCUS > LENS INIT > Press the joystick '☟' straight down for about 2 seconds.
