OPERATION
After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board or in DMX-controlled mode via any commercial DMX controller and with Quick-
DMX USB radio transmitter/receiver.
Operating buttons
Button
MENU
ENTER
UP
DOWN
Menu structure
Mode
DMX mode
Preset colors
Automatic mode
Sound control
Running speed in
automatic mode and
sound control
Microphone sensitivity
for sound control
Color mix
Dimmer
Sound control silent
scene
Behavior in case of
missing DMX signal
Slave mode
IR remote control
Firmware version
Function
Selects the operating mode or returns to the initial screen.
Activates a value to be modified or saves a value when modifying.
Selects the next menu item or increases values when modifying.
Selects the previous menu item or decreases values when modifying.
Display
8CH
Addr 6CH
4CH
Stat
Auto
Soun
SPEE
SEnS
Colo
diMM
SILE
Lost
SLAU
InFr
V1.0
8-channel mode and start address
d001-512
d001-512 6-channel mode and start address
d001-512 4-channel mode and start address
S 01-18 Constant lighting in one of 18 colors
Au 1–2 Auto program
So 1–2 Sound program
Program running speed
SP 1-9
slow > fast
Microphone sensitivity
SE 1-9
low > high
r000-255 Red 0-100%
g000-255 Green 0-100%
b000-255 Blue 0-100%
U000-255 White 0-100%
Total brightness
dI 1-dI 9
dark > bright
on LEDs off if there is no music signal
oFF LEDs remain on if there is no music signal
blac LEDs switched off
hold Most recent DMX value is held
FULL All LEDs light at 100% brightness
Stat Last selected static color (1-18)
Auto Last selected auto program (1-2)
SLAU Slave mode
IR remote control on
on
oFF IR remote control off
V1.0 Firmware version number
