EN
3.2.1.5.2
Cable compensation by...
Length x cross-section
Resistive offset
Temperature offset

Cable compensation via temperature offset

3.2.1.5.3
Cable compensation by...
Length x cross-section
Resistive offset
Temperature offset

Saving settings on the measuring module

3.2.1.6
Setup Fig. 138 4G/638 4G
Cable compensation
save to meas. module
back...
Attention!
After entering the sensor settings, carry out the
function "Save in measuring module! This is
the only way that the configuration set on the
portable measuring instrument is permanently
saved on the measuring module.
60 /184 – K410013800005-00 / 01.2024 – © www.kemper-group.com

Cable compensation via resistance offset

Wire resistance
min: 000.00 - max: 100.00
000.00 Ohm
Temperature offset
min: -10.00 - max: 10.00
00.00 K
Setup Fig. 138 4G/638 4G
Cable compensation
saving data...
save to meas. module
back...
If writing is not carried out and the measuring
cable from the measuring module or portable
measuring instrument is removed, you have to
enter the sensor settings for further measurements
again!
+1
...
- 1
+1
...
- 1
Setup Fig. 138 4G/638 4G
Cable compensation
Data saved!
save to meas. module
back...
