Information on the glycol content

3.2.1.4
Setup Fig. 138 4G/638 4G
Sensor measuring range
Pipe inner diameter
Glycol - Propylene
Glycol percentage - 0%

Cable compensation

3.2.1.5
All temperature sensors are evaluated by the
portable measuring instrument as a 2-wire
measurement. The measurements are falsified by
the cable resistance.
Setup Fig. 138 4G/638 4G
Cable compensation
save to meas. module
back...

Cable compensation via length and cross-section

3.2.1.5.1
Cable compensation by...
Length x cross-section
Resistive offset
Temperature offset
2.7.1.3
It is recommended to balance out the resistance
deviations, caused by cable extensions from the
temperature sensor to the measuring module with
the Cable compensation menu item.
3.2.1.5.1 - 3.2.1.5.3
Wire length
min: 00.00 - max: 99.99
00.00 m
Wire diameter
min: 00.00 - max: 99.99
00.00 mm²
