Kemper CONTROL-PLUS Montage- Und Bedienungsanleitung Seite 39

Table of contents
3 Connecting the portable measuring instrument to a sensor measuring module
Figure 138 00 011
3.1 Changing the designation of the sensor measuring module
3.2 Selecting and setting a sensor
3.2.1 Flow and temperature measurement valve Figure 138 4G | 638 4G
3.2.1.1 Selecting the sensor measuring range
3.2.1.2 Information on the pipe diameter
3.2.1.3 Information on the glycol type
3.2.1.4 Information on the glycol content
3.2.1.5 Cable compensation
3.2.1.5.1 Cable compensation via length and cross-section
3.2.1.5.2 Cable compensation via resistance offset
3.2.1.5.3 Cable compensation via temperature offset
3.2.1.6 Saving settings on the measuring module
3.2.2 Pressure sensor Figure 138 00 006
3.2.3 Temperature sensor Pt1000
3.2.4 Temperature sensor Pt100
3.2.5 0-20 mA sensors
3.2.5.1 Specifying the lower value
3.2.5.2 Specifying the upper value
3.2.5.3 Specifying the unit
3.2.5.4 Specifying the settings
3.2.6 4-20 mA sensors
3.2.7 0-10 V sensors
3.2.8 Frequency sensors 0-500 Hz
3.3 Saving setting in the measuring module
3.4 Buffering setting in the portable measuring instrument
3.5 Loading setting from the portable measuring instrument buffer
3.6 Initialising measuring module
3.7 Selecting the units displayed during a measurement
3.7.1 Unit for the volume flow
3.7.2 Unit for the temperature
3.7.3 Unit for the flow velocity
3.7.4 Unit for the pressure
4 Using the web server
4.1 Connecting to the web server
4.2 Transferring measurement data from the portable measuring instrument
to a terminal device
4.3 Loading and installing a software update to the portable measuring instrument 71
5 Battery change
© www.kemper-group.com - 01.2024 / K410013800005-00 - 39 /184
56
57
57
57
58
58
58
59
59
59
60
60
60
61
61
62
62
63
64
65
65
65
66
66
66
67
67
67
68
68
68
69
69
70
70
70
72
