Connections and mechanical components

Connections and
mechanical com-
ponents
(1)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
GAS 2 GAS 1
IN IN
(2) (3) (4)
Lid
Connection GAS 2 IN
Connection GAS 1 IN
SpeedNet connection
Mounting fixture (optional)
OPT/i Mounting gas regulator
Dummy cover
Connection GAS 1 OUT
Connection GAS 2 OUT
GAS 1
OUT
(5)
(6) (7)
GAS 2
OUT
(8)
