Installing the gas regulator

Safety

Danger from incorrect operation and work that is not carried out properly.
This can result in serious personal injury and damage to property.
▶
▶
▶
NOTE!
After modifications, repairs, and installations or conversions, a safety inspec-
tion must be performed in accordance with the Service Instructions of the de-
vice.
▶
▶
▶

Scope of supply

Required tools

-
-
-
-
-
WARNING!
All the work and functions described in this document must only be carried
out by technically trained and qualified personnel.
Read and understand this document in full.
Read and understand all safety rules and user documentation for this equip-
ment and all system components.
Observe the relevant national and regional requirements and standards.
The safety inspection must only be conducted on a completely assembled
device.
If a defect is identified during the inspection, the safety inspection must be
repeated once the defect has been eliminated.
(8) (7)
TORX® screwdriver TX25
Philips® screwdriver
Step drill 14 mm
17 mm flat spanner
Knife
(1) 2x gas hose
(2) 2x angled connection
(1)
(3) Gas sensor
(4) Plug-in coupling
(2)
(5) Control valve
(3)
(6) 2x M3 x 20 mm screw
(4)
+ washers
The optional gas regulators for
(5)
plasma gas, forming gas, and
carrier gas are each equipped
(6)
with 2 M3 x 40 mm screws.
(7) Shielding gas connection
(8) Cable
