8 Power supply

NOTICE! The base unit can be operated both with the sup-
plied power adapter or with batteries.
Base unit
1.
2.
ATTENTION! Make sure that the plug adapter is firmly
and securely fastened in the adapter fixture of the AC
power adapter before proceeding!
3.
4.
5.
6.
NOTE: Alternatively, operation using batteries (LR03
AAA/LR03) is also possible.
The display goes into sleep mode during battery opera-
tion and can be activated for approx. 15 Seconds by
pressing the snooze button. To do this, proceed as fol-
lows:
7.
8.
9.
14 / 44
Press and hold the locking knob on the adapter fixture
of the AC power adapter. At the same time, insert the
desired plug adapter into the adapter fixture and turn
it in as far as it will go in the "LOCK" direction. Release
the locking knob.
Insert the DC barrel connector into the DC connection
socket on the base unit.
Insert the AC power adapter with the previously moun-
ted plug into the power outlet.
The device is powered on directly.
Wait until indoor temperature is displayed on the base
unit.
To replace the plug adapter, hold down the locking
knob and turn the plug adapter in the "OPEN" direction
and remove it from the adapter holder. Then perform
step 1 to mount another plug adapter.
Remove the battery compartment cover.
Insert batteries into the battery compartment. Make
sure that the batteries are correctly aligned (+/- poles).
Replace the battery compartment cover.
