• «Integrated charging» function:
The SHOWROOM mode (outside of the «no battery» function) incorporates an automatic charging algorithm adapted to all types
of batteries (lead and lithium), in order to guarantee an optimal charge level for demonstration vehicles. This function is perfectly
compatible with the presence of consumers on the battery.
1
U
I
Analysis
Step 1: Analysis
Analysis of the battery condition (charge level, inversion, etc.)
polarity, wrong battery connected, etc).
Step 2: Charging
Fast charging at maximum current until U1 is reached
(ex: 13.8 V to )
Step 3: Absorption
Charge under constant voltage U1 (ex: 13.8 V in
Maximum duration 1 hour.
• Abnormal undervoltage protection:
This protection prevents the risk linked to possible short circuits or battery being too damaged. The charger will automatically stop
if the voltage is abnormally low for more than 10 minutes.
TESTER MODE
General navigation :
1 Use the arrows to select the test to be performed
2 Press the START/STOP button to start the test
• Voltage test:
This mode allows you to view the voltage at the terminals of the charging clamps and thus use
your Autocom CHARGER as a voltmeter, in order to measure the battery voltage.

• Start-up test:

The purpose of this mode is to evaluate the state of a vehicle starting system (starter + battery) when the engine is turned on.
This test must be done with the battery connected to the vehicle.
8 8
2 3
Charging Absorption
Autocom CHARGER
4
Equalization /
Complement
Step 4: Complement
Gradual increase of the voltage up to U2
(ex: 14.4 V to
Step 5: Equalization / Balancing
Maintaining the voltage U2 (ex: 14.4V at
Maximum duration 2 hours.
Step 6: Power supply mode
).
Application of the selected voltage.
6
5
Power supply mode
Balancing
). Maximum duration 2 hours.
TESTER MODE
EN
).
Voltage test
Voltage test
U=12.1V
