2 Confirm the recording of the charging data.
3 The charger will then copy the charging data to the USB stick as files, « .CSV »
Custom configuration
List of modes and profiles available for customization:
CHARGE MODE
Charge Charge
type: profiles
normal
AGM
water
Easy
Pb-CHARGE
boost
recovery+
Ca/Ca recov
LFP/LiFePO4
Li-ion std
Li-CHARGE
LFP cell+
Li-ion cell+
POWER MODES
SHOWROOM
DIAG+
CHANGE BAT.
STARTER MODE
POWER SUPPLY
Li-SUPPLY/LFP
Li-SUPPLY/Li-ion
MISCELLANEOUS
TESTER MODE
CONNECTIVITY MODULES
Your Autocom CHARGER is equipped with a DB9 type socket allowing you to connect various additional modules such as a printer,
Ethernet or other module in order to further extend the possibilities of your charger.

LIST OF ERROR CODES

Error code
Err01: Int_1 - Err02: Int_2
Err23: Int_3 - Err24: Int_4
Err03: Fuse_NOK
Err04: T>Tmax
Err05: (+)(-)
12 12
Charging voltage
2.40 V/cell
2.45 V/cell
2.45 V/cell
2.40 V/cell
Modes detailed on page 4.
2.42 V/cell
2.40 - 2.50 V/cell
2.45 - 2.66
V/cell
3.60 V/cell
Charging profile for standard lithium-ion batteries based on Manganese or Cobalt (NMC,
4.20 V/cell
LCO, LMO, MCO...)
Charging profile dedicated to LFP (Lithium Ferro Phosphate) type lithium-ion cells with
3.60 V/cell
selection of the number of cells in series to be charged.
Charging profile dedicated to standard lithium-ion cells based on Manganese or Cobalt
4.20 V/cell
(NMC, LCO, LMO, MCO...) with selection of the number of cells in series to be charged.
Modes detailed on page 6.
Mode designed to supply LFP (Lithium Iron Phosphate) type lithium-ion cells with selection of the number of cells
in series, adjustment of the voltage and current to be applied.
Mode designed to supply standard lithium-ion cells based on Manganese or Cobalt (NMC, LCO, LMO, MCO...) with
selection of the number of cells in series, adjustment of the voltage and current to be applied.
Allows to check the state of the battery, to evaluate the starting of the vehicle as well as the operation of the
alternator
Meaning
Electronic problem
Defective charger
Output fuse out of order
Abnormal overheating
The polarity has been reversed on the
clamps
Autocom CHARGER
Contact the reseller
Have the fuse replaced by a qualified person
Contact the reseller
Connect the red clamp to the (+) and the black clamp to the (-)
of the battery.
EN
Continue?
Yes
Loading
Solutions
