4.0 Transport
ATTENTION! Always check delivery for completeness and damage! The carrier (forwarder or railway) is to be informed
immediately in case of transport damages. (s. yellow leaflet)
5.0 Setting up the machine
The drill should be set up on a solid base and aligned using a spirit level. If the machine is to be bolted to the base, it should be
ensured that the base plate does not warp in the process.
6.0 Installation
The machine has been installed ready for use. Please check whether type of current, current voltage and fusing agree with the
prescribed values. There must be a protective earth terminal. Mains fusing 10 A.
Attention! Take notice of the right rotation (right-hand) of spindle.
7.0 Commissioning
The parts with rust-inhibiting coating should be cleaned carefully. The column should then be lubricated. The head should be
moved several times since condensation may have formed in the head guide.
8.0 Switching the machine On and Off
Insert plug into socket. The machine can be switched on or off using the two push-buttons on the front .
9.0 Changing speed
After the machine has been switched on, the spindle speed of the machine can be adjusted on the potentiometer (6). Attention!
Do not forcefully overturn the potentiometer. The set speed will be shown on the dial. Attention! A dirty light barrier will
cause improper work of the machines 4,6,8, 10 STW. We recommend a monthly cleaning with compressed air. Please
remove hood as per paragraph 12.0.
10.0 Adjusting the drilling depth
without limit stop: The drilling depth is shown on the scale of the stop ring (30).
with limit stop: Place drilling tool with drill lever (28) onto the workpiece. Push stop ring (30) axially to the left and set the
required drilling depth.
11.0 Adjusting the head 4, 6, 8, 10 STW
The drill head (1) is adjusted as follows for work - pieces or tools of different heights. Unscrew the clamping lever (37). Take
hold of the bottom of the drill head (1) near the column and adjust the drill head upwards or down-wards (10 STW). For 4/6/8
STW use the hand-wheel (38). Tighten the clamping lever (37).
11.1 Adjusting the head 13 STW
The drill head (27) is adjusted as follows for work - pieces or tools of different heights. Unscrew the clamping lever (28). Take
hold of the bottom of the drill head (27) near the column and adjust the drill head upwards or down-wards (13 STW). Tighten the
clamping lever (28).
12.0 Dismantling the protective hood 4, 6, 8, 10 STW
Attention! Disconnect from the mains. Adjust the drilling head in the upmost position. Dismantle potentiometer button (6) by
removing the screw . The potentiometer button (6) can now be pulled off.
Unscrew plastic nut (14), slightly lift the back of the protective hood (9) and pull it up and over the potentiometer shaft carefully.
For 4/6/8 STW unscrew screw additionally and remove the hand-wheel (38). Fit in reverse order.
12.1 Belt tension 13 STW
Attention! Disconnect from the mains.
The belt (15) must be tensioned if the penetration power drops.Disconnect the mains plug and unscrew the lower guard plate
(3). Slaken the two internal screws slightly and remove the black plastic plug (36) from the frontplate (35). Tension the motor
slightly via the threaded spindld using a screwdriver. Now fully retighten the two hexagon socked screws.
13.0 Changing the belt
Attention! Disconnect from the mains.
Dismantle protective hood as des cribed in section 12.0. Unscrew screw and remove photoelectric barrier.
Unscrew screw and pull motor to the front. Remove belt over the spindle pulley by turning.
The new belt can be fitted in reverse order.
14.0 Care reference
For cleaning each standard cleaning agent for plastic is suitable.
6
217267 D/E
