OVERVIEW
1
7 8
1 3.5 mm audio output jack
2 Memory card output slots
3 USB-A (Gen 2 10G) output connectors
4 USB-C (Gen 2 10G) output connector
5 QC output connector
6 S/PDIF output connector
7 Connector
8 USB-C output connector
9 Input USB-C connector
10 HDMI output connectors
11 DP output connector
12 VGA output connector
13 Ethernet output connector
14 USB-A output connectors
8 ENGLISH
2
6
9 10
3 4
11
for headphone connection
to insert memory cards
for connecting external devices
for connecting external devices
for connecting peripheral devices and for charging.
to connect external equipment (e.g. amplifier)
to connect the mains adapter (max. 120 W)
to connect a PD adapter
for connecting to a computer.
for connecting to a monitor or TV
for connecting to a monitor with DP support
for connecting to a monitor with VGA support
for connecting to a LAN
for connecting external devices
